Temporary bypass authorizations supporting document
Important: Notification must be completed before submitting an application. If you have any questions about your application, please contact eu-ww@ec.gc.ca.
Summary
Temporary bypass authorizations (TBAs) allow the owner or operator of a wastewater system to bypass one or more treatment processes for a defined period of time. This could result in exceeding effluent standards outlined in the Wastewater Systems Effluent Regulations (the Regulations). TBAs may be issued in the following circumstances:
- to allow owners or operators to perform necessary construction or maintenance work at their wastewater treatment plant
- for anticipated events out of control of the owner or operator
A temporary bypass can be authorized from one or more final discharge points and/or overflow points.
Eligibility
To be eligible for a TBA, the applicant must meet the following criteria:
- treatment capacity is reduced due to:
- construction work to make changes to the system
- maintenance of the system
- an anticipated event outside the control of the owner or operator
- the bypass is designed, within technical and economic constraints to minimize the:
- volume of undertreated effluent deposited
- concentrations of deleterious substances
Deleterious substances
Deleterious substances in wastewater are carbonaceous biochemical oxygen demand (CBOD), suspended solids (SS), total residual chlorine (TRC) and un-ionized ammonia as specified in section 5 of the Regulations.
Any planned release of deleterious substances that may enter water frequented by fish, or any place, under any conditions where it may reach water frequented by fish, and that is not authorized by a temporary bypass authorization issued under the Regulations, is considered an unauthorized deposit and subject to subsection 36(3) of the Fisheries Act. Please consult our factsheet on unauthorized deposits for more information.
Before applying
Determine bypass category
Applications for TBAs are based on risk. Applications fall into category 1 (low risk), category 2 (medium risk) or category 3 (high risk), based on:
- quality of effluent deposited during the bypass
- volume of wastewater effluent to be deposited during the bypass (in m3)
- duration of the bypass (in hours)
- whether the work reduces the treatment capacity, which could result in the release of untreated wastewater mixed with precipitations during rainfall events,
- time required to complete the work (in hours)
- receiving environment criteria (whether the release occurs in or near a shellfish harvesting area or a critical habitat for a protected aquatic species)
A bypass will fall under one of the 3 options below based on the wastewater effluent quality:
The 3 options are:
- wastewater effluent receives physical or biological treatment
- wastewater effluent receives no treatment
- wastewater effluent release is due to potential precipitation events during a period of reduced treatment capacity
Applicants must use the figure below that best describes their effluent to determine the corresponding category.
Option 1: Wastewater effluent receives physical or biological treatment
Wastewater undergoes any treatment process, other than preliminary treatment, for the purpose of removing SS and/or CBOD matter. Examples of physical or biological treatment that would qualify include aerated lagoons and clarifiers.
Wastewater effluent received physical or biological treatment
Long description
Is the volume greater than 500,000 m3 OR is the duration greater than 90 days? If yes, does the receiving environment meet the criteria? If yes, it’s a category 3, if no, it’s a category 2.
Is the volume less than or equal to 25,000 m3 AND the duration is less than or equal to 10 days? If yes, does the receiving environment regularly receive wastewater? If yes, it’s a category 1, if no, it’s a category 2.
All other bypass volumes and durations are a category 2.
Option 2: Wastewater effluent receives no treatment
During the bypass, wastewater receives no physical or biological treatment or only undergoes preliminary treatment. Examples of preliminary treatment that would qualify include screening and grit removal.
Wastewater effluent received no treatment
Long description
Is the volume greater than 50,000 m3 OR is the duration greater than 30 days? OR does the receiving environment meet the criteria AND have a volume greater than 25,000 m3 OR duration greater than 15 days? If yes, it’s a category 3. If no, it’s a category 2.
Is the volume less than or equal to 2,500 m3 OR is the duration less than or equal to 2 days and the bypass does not meet all conditions of a category 3 bypass? If yes, does the receiving environment regularly receive wastewater? If yes, it’s a category 1. If no, it’s a category 2.
All other bypass volumes and durations are a category 2.
Option 3: Wastewater effluent release is due to potential precipitation events during a period of reduced treatment capacity
The construction or maintenance work will reduce the capacity of the wastewater system. Untreated wastewater mixed with surface runoff and stormwater will be deposited only if a precipitation event occurs during the period of reduced treatment capacity. The release that may result from the reduced capacity would fall under this option. A precipitation event excludes the melting of snow or ice.
This figure indicates the duration of the period of work, not the duration of the bypass. The period of work is the period that the system will have a reduced capacity due to construction work or maintenance. The work duration is used to determine the bypass category, however the authorization is tied to the duration of the bypass.
Wastewater effluent release is due to potential precipitation events during a period of reduced capacity
Long description
Is the volume greater than 100,000 m3 OR is the work duration greater than 60 days? If yes, does the receiving environment meet the criteria? If yes, it’s a category 3. If no, it’s a category 2.
Is the volume less than or equal to 5,000 m3 OR is the work duration less than or equal to 4 days and the bypass does not meet all conditions of a category 3 bypass? If yes, does the receiving environment regularly receive wastewater? If yes, it’s a category 1. If no, it’s a category 2.
All other bypass volumes and work durations are a category 2.
Receiving environment criteria
Meeting 1 or 2 of the following receiving environment criteria could cause a bypass to fall into a Category 3 (high risk): shellfish harvesting area, or, critical habitat of a protected aquatic species.
Shellfish harvesting area
This receiving environment criterion is triggered if a shellfish harvesting area is within 1,500 meters of the bypass location.
To determine if this criterion applies to the bypass, use the SHELLI map.
Select any species in one of the 2 dropdown menus. This will activate a layer option in the left menu.
Section of shellfish harvesting webpage
Long description
Shellfish harvesting map where users choose a shellfish species from a dropdown (separate options for Pacific and Atlantic), and the map updates to show where harvesting is open or closed for that species.
This map contains layers for Environment and Climate Change Canada (ECCC), Fisheries and Oceans Canada and the Canadian Food Inspection Agency. Ensure you select only the ECCC layer by selecting only the boxes checked in the circle below. Zoom in to see the layer.
Shellfish harvesting map
Long description
Shellfish harvesting map shows how to select the ECCC layer and the associated map that displays harvesting areas that are approved, conditionally approved, conditionally restricted, restricted or prohibited.
Areas on the map that would qualify as a shellfish harvesting area include:
- approved (green)
- conditionally approved (green with crosses)
- conditionally restricted (yellow with crosses)
- restricted (yellow)
The areas in red are prohibited and are not shellfish harvesting areas. The areas in blue are unassessed and are not considered a shellfish harvesting area.
If you have a Conditional Management Plan (CMP) with Department of Fisheries and Oceans (DFO), or are unsure if you will be releasing within a shellfish harvesting area, contact eu-ww@ec.gc.ca for assistance.
Critical habitat
An identified critical habitat for a federal protected aquatic species is within 500 meters of the bypass location.
To determine if this criterion applies, use this critical habitat map. Tip: be patient - the map takes time to load. All areas shown in red qualify as Critical Habitat for aquatic species at risk.
Notify
Before submitting an application, the applicant must:
1. Notify the public, and any community or Indigenous group if there are reasonable grounds to believe the bypass could impact them. They must also be notified if they have used or may use the receiving environment before, during or after the bypass.
Consider that the public, community or Indigenous group may be affected due to the bypass impacting water usage, such as:
- drinking water
- subsistence fishing and harvesting
- sports (fishing, water sports, etc.)
- recreational activities
- water aesthetics (odor, visible changes, etc.)
Considerations for the applicant when determining who to notify:
- environmental impacts that may result due to the volume, duration, and concentration of deleterious substances of the bypassed effluent
- current and anticipated uses of the receiving environment
- existing relationships with neighboring communities, Indigenous communities, landowners, etc.
It is the responsibility of the applicant to determine the acceptable radius to notify Indigenous communities, depending on the volume and duration of effluent released. Consider notifying an Indigenous community if the head office is within 25 km of the point of entry (upstream or downstream).
Use the Government of Canada website ATRIS to identify Indigenous groups that may be affected by the planned bypass.
When you notify, consider many communication methods, including:
- written letters
- emails
- social media campaigns
- public websites
- written notices
- local media (newspaper, radio)
- phone calls
Consider who is being notified and existing relationships when deciding what method(s) of communication to use.
Provide a rationale for the selected method of communication, for example:
- post on social media feed that receives high activity/interactions
- send emails if the community indicated this is their preferred method of communication
Best practices for notification to consider:
- explain why the work is necessary and why the bypass cannot be avoided
- highlight expected impacts or lack of expected impacts
- outline the mitigation measures you will implement
- include approximate duration of bypass and effluent quality expected
- if there is potential for delays, consider not specifying exact dates
- a more detailed notification can be sent or posted online closer to the bypass
If you would like a sample notification that you can tailor to your specific bypass and situation, please contact eu-ww@ec.gc.ca.
ECCC will review each application to ensure adequate notification has been given. If notification is inadequate, the application is considered incomplete and the authorization may not be issued.
The Regulations require that the results (for example, news article, online comments, concerns) of notifications and engagement with those who could be impacted be shared with ECCC as part of your application. Any feedback received can be shared via email or in the application itself.
Any results of notification received since the application was submitted should be included in the final report.
2. Notify ECCC’s Shellfish Water Classification Program if the proposed bypass will result in the deposit of effluent within a 20 km radius of marine waters or a shellfish harvesting area.
This notification should include:
- name of the wastewater system
- name of the body of water and the latitude and longitude of the point(s) where the deposit will occur
- approximate duration in hours
- estimated volume in cubic meters
- expected effluent quality
Send the notification to Shellfish Water Classification Program with eu-ww@ec.gc.ca in cc on the email.
For applications in NS, PE, NB and NL, email: atlantic.shellfish@ec.gc.ca.
For applications in QC, email: f.dmsqepcecquebec-wqmsdswcpquebec.f@ec.gc.ca.
For applications in BC, email: pcec-pacifique-rimd-swcp-pacific-dgir@ec.gc.ca.
Separate from this notification, if your municipality has a Conditional Management Plan (CMP) with Department of Fisheries and Oceans (DFO), you are required to provide notification of the planned work as per your agreement.
How to apply
The applicant must submit a temporary bypass application through the online Effluent Regulations Reporting Information System (ERRIS).
You can start an application and return to it at any time before submitting. Be sure to save your progress as you go. The application must be submitted a set number of days before the start of the bypass. The number of days is determined by the level of risk of the release:
- at least 21 days before the deposit if the release is Category 1 (low risk)
- at least 45 days before the deposit if the release is Category 2 (medium risk)
- at least 90 days before the deposit if the release is Category 3 (high risk)
To be eligible, the application must meet specific requirements based on the category and level of risk. The applicant must include this information in the TBA application (section 44).
Review this guidance document completely to ensure you have all the correct and complete information before submitting your application. Annex 1 contains examples of the required information. If you have any questions or would like support with your application, contact eu-ww@ec.gc.ca.
Category 1
Required information for the application.
The period (start and end dates) of the authorization
- Should correspond to the period of the construction work, maintenance or response to an anticipated event that could result in a bypass
- This is the period that the applicant would be authorized to release undertreated effluent
- Any period of construction time before or after the bypass that does not involve potentially releasing undertreated effluent, should not be included in the application (for example, site preparation and cleanup)
- However, consider adding buffer to the start and end date to account for any uncertainty
The approximate duration of the bypass (in hours)
- The duration of the bypass is the amount of time that undertreated wastewater will be deposited due to work being performed
- The authorization is only for the duration of bypass specified in the application
- Report a reasonable estimate for the duration and include a buffer if there is uncertainty
- Bypass duration should be less than or equal to the work duration
The duration of the work (in hours)
- The duration of the work is the amount of time the work will be performed that may result in a bypass
- This is particularly important for Option 3 (bypasses that occur due to precipitation during periods of reduced capacity)
- Report a reasonable estimate for the duration of work and include a buffer if there is uncertainty
The estimated volume (m3) of the deposits and an explanation of how the volume was estimated
- Provide the volume of undertreated wastewater that will be deposited in m3
- Historical data can be used to estimate the volume
- The estimated volume should factor in the time of year and time of day, if relevant
- State any assumptions made about the expected volume
- Consider the capacity of the system while a treatment train is offline
- Estimate the potential overflow volumes based on historical data on wet weather flows
- Factor in expected rainfall for that time of the year based on recent historical data
- Similarly, look at past data for the average durations of wet weather flows to help determine a reasonable bypass duration
- The authorization is only for the volume of the deposits specified in the application
- Any deposits that exceed the volume stated in the application would be unauthorized
- Ensure the estimate is realistic while still having enough buffer that, should there be a wet weather event, the bypass will be within the authorized volume and duration.
A description of the treatment, if any, that will be applied to effluent prior to deposit, and whether deposits will be caused by precipitation events occurring during a period of reduced capacity
- Provide a description of the treatment that effluent will receive
- Provide expected effluent quality data on SS, CBOD, un-ionized ammonia and total residual chlorine, if available
- If the planned work will reduce the treatment capacity of the wastewater system, provide information on the normal treatment capacity and expected reduced capacity
- If possible, estimate effluent quality of the diluted effluent
An explanation of how the bypass is designed to minimize the volume of effluent deposited and the concentrations of deleterious substances
- Describe how the bypass is designed to minimize the volume of effluent deposited and the concentration of deleterious substances (CBOD, SS, total residual chlorine and un-ionized ammonia)
The point(s), in latitude and longitude, from where effluent will be deposited
- Select the final discharge point(s) or overflow point(s) where effluent will be deposited during the bypass
- If the point is not found in the drop-down list, add it first to the Identification Report in ERRIS
- The “main” discharge point selected should represent the point where the largest volume of effluent will be bypassed
- Select additional discharge points under “other” discharge points
- If the system has multiple final discharge points, please contact the Wastewater Section (eu-ww@ec.gc.ca) for support to complete the application
A description of the water or place where effluent will be deposited (receiving environment)
- Describe the water or place where effluent will be deposited
- State the name of the water or place and the name of the larger body of water, if applicable
- Include a description of the use of the water or place (for example, fishing, recreation, etc.)
- If there are different waters or places for each point where effluent may be deposited, list and describe them in the application
- Provide additional information specifying which point enters which waterbody
If the bypass is at an overflow point, a statement indicating whether the water or place the overflow point releases into regularly receives wastewater under normal conditions
- State whether the water or place where bypassed effluent will be deposited regularly receives wastewater under normal conditions
- The regular wastewater deposited could be from the system’s final discharge point, or another point
- Provide information to support that the environment regularly receives wastewater
A description of the work and an explanation of why it is necessary to bypass at least one of the treatment processes normally applied to wastewater
- Provide details on the work and why it cannot be completed without a bypass
- Aerial photos and arrows of process flow may be helpful to support the explanation
A description and the results of notifications to and engagements with members of the public, communities or Indigenous groups that may be impacted by the proposed bypass
- Specify who was notified, and the method(s) used to notify them
- Provide a summary of any responses received from the people and/or groups notified. If concerns about the bypass were raised, explain how the concerns will or have been addressed
- If no responses have been received at the time of submission, the application can still be submitted. A summary of responses to notification can be provided to ECCC via email (eu-ww@ec.gc.ca) after an application has been submitted
An explanation of how the bypass follows the previously declared plan to reduce bypasses over time (if required)
- If a wastewater system has previously received a TBA and, as a result, the owner declared the existence of a plan to reduce large and untreated bypasses in the future, all subsequent applications must acknowledge that plan
- Explain how the proposed work aligns within the scope of the previously declared plan
A list of measures that will be implemented to avoid or mitigate the adverse effects of the bypass on fish, fish habitat or the use of fish by persons
- Provide a list of measures that will be implemented before, during or after the bypass
- The measures implemented should avoid or limit the effects on the receiving environment
- These measures should be tailored to the specific work and the resulting bypass
- More information on mitigation measures is provided in the section below and examples are in the Annex
- Include the choice of appropriate timing for the proposed work to reduce the risk of harm
Category 2
Provide all information required for a category 1 application. In addition, provide a more detailed description of mitigation measures that will be put in place to avoid or lessen the negative effects of bypass on fish, fish habitat or the use of fish by persons.
- These measures should be rigorous and tailored to the system and work being performed
- The description should include an overview of the measures, the dates during which the measures will be implemented and what the measures will achieve
The Annex provides more information on mitigation measures.
Category 3
Provide all information required for categories 1 and 2 applications. In addition, provide the following information.
A review of methods considered but not used to avoid or minimize the bypass, including their technical feasibility and an estimate of costs
- Feasibility and costs should consider the location or remoteness of the system
- Recommend including 1 or 2 alternatives considered with an order of magnitude cost
An assessment of the geographical scope where the effluent mixes with the receiving waters and where there is a distinguishable difference from the ambient water
- Include a description of the methodologies used to prepare the assessment
- An existing plume delineation model would be acceptable if it shows the extent of the bypass
A detailed description of the monitoring of the effluent or of the receiving environment
- The description must be based on the assessment of the geographical scope of the bypass to assess the effectiveness of the mitigation measures
- Provide a detailed plan and schedule for monitoring the effluent and/or the receiving environment before, during and after the bypass occurs
- Consider whether the plan should align with historical sampling points
- Consider collecting pre-bypass baseline samples and post-bypass samples after the plume has fully dissipated (such as 2 weeks)
- Consider including biological markers such as E. coli
- Consider outlining what steps would be taken if adverse effects are observed
Mitigation measures
Applications for all categories require information on mitigation measures that will be implemented to avoid or reduce the effects of the bypass on fish, fish habitat or the use of fish by persons. These measures should be specific to the work being performed, the resulting bypass and the receiving environment.
Consider more sensitive receiving environments in the development of mitigation measures and when selecting the timing of the work. Sensitive receiving environments can include:
- marine protected area
- ecologically and biologically sensitive area
- Ramsar convention wetland
- national park
- national marine conservation area
- culturally significant area for Indigenous peoples (consider land claims found in the Aboriginal and Treaty Right Information System as well as regional knowledge)
- critical habitats under federal regimes
- critical habitats under provincial regimes (check provincial resources)
- other concerns (for example, spawning season, freshet, algae, river flows, etc.)
Provide an explanation on how the proposed mitigation measures will reduce the impacts on the receiving environment during the bypass. If it is determined that the bypass will have adverse effects on fish and fish habitat that cannot be mitigated, ECCC may refuse the application.
Additional information
ECCC may request additional information if it is required to assess the potential adverse effects of the bypass on fish, fish habitat or the use of fish by persons. ECCC must specify in writing the information needed and a timeline for providing it.
For any questions or support with your application, please contact eu-ww@ec.gc.ca.
After a temporary bypass authorization has been issued
Conditions on temporary bypass authorizations
A TBA holder is authorized to deposit effluent during the period of work as long as they meet the conditions specified in their authorization. This includes implementing the mitigation and monitoring measures of the application, including:
- the latitude and longitude of any final discharge point or overflow point from which effluent is deposited
- the period of the authorization (start and end dates)
- the maximum duration and volumes of the deposit(s)
- the level of treatment, if any
- implementation of the mitigation and monitoring measures of the application
Compliance obligations
During the TBA, the holder must comply with other sections of the Regulations.
If the bypass occurs at least at one final discharge point, the owner or operator must continue to sample, monitor and submit report at the final discharge point, per usual.
- While the authorization is in effect, it is not required to comply with the effluent quality standards at the final discharge point
- If an acute lethality test fails during the authorization, increased testing is not required; however, systems on reduced sampling must return to normal sampling frequency during bypass and after bypass until conditions for reduced sampling are met again
- If monitoring equipment is normally used but is inoperable during the bypass, a method of estimation can be used to determine the daily volume in accordance with subsection 7(4)
- If the system has Combined Sewer Overflow (CSO) points, the TBA holders must continue to monitor and report as required
- If the wastewater system has more than one final discharge point, please contact eu-ww@ec.gc.ca to determine the compliance obligations specific to the authorization
For a bypass that occurs only at overflow point(s), the owner or operator must continue to sample, monitor and submit report at the final discharge point, per usual.
- While the authorization is in effect, it is still required to comply with the effluent quality standards at the final discharge point of the wastewater system
- If monitoring equipment is normally used but is inoperable during the bypass, a method of estimation can be used to determine the daily volume in accordance with subsection 7(4)
- If the system has CSO points, the owner or operator must continue to monitor and report as required, including at the CSO points that may be the subject of this authorization
Corrected information
A TBA can be extended, modified or reissued after it has been approved if a situation arises (for example if work is delayed). The TBA holder must notify the authorization officer as soon as possible of any changes to the proposed bypass. The TBA can only be modified if it is still within the limits of the authorization (the maximum volume, duration, and dates of the bypass have not been exceeded, and the minimum level of treatment specified in the application is maintained). If the category of the TBA changes, the TBA may be reissued if the additional information required under the new category has been submitted. Please note, ECCC requires time to review and re-issue an authorization.
Final report
The TBA holder must, within 90 days after the last day of the period of the authorization, send to ECCC a final report that contains:
- the actual dates of the bypass
- the actual duration of the deposits (in hours)
- the actual or estimated volume of all deposits (in m3)
- a description of the actual treatment applied to effluent, if any
- a description of how the mitigation and monitoring measures were implemented during the bypass, and
- the results of any sampling and monitoring conducted during the bypass period, if applicable
- this includes samples of the bypassed effluent and any samples collected in the receiving environment
- any results of notification received since the application was submitted (for example, news articles, feedback online, etc.)
For category 2 bypasses with no treatment, category 2 bypasses that are due to precipitation events during a period of reduced capacity and all category 3 bypasses, provide the following information:
- confirmation of the existence of a plan that describes future planned modifications to the wastewater system and other measures that will be taken to reduce the need for future temporary bypass authorizations
- the plan must include a schedule for implementation
- a goal of the plan should be to reduce adverse effects on fish, fish habitat or the use of fish by persons when performing work that requires bypassing effluent
- a declaration that this plan is available to the public
Existing plans that have already been developed for a wastewater system such as asset management plans or combined sewer overflow reduction plans can be considered. They must contain sufficient information to meet the criteria.
Applicants should provide information on their plan and how it is publicly accessible, for example by providing a website link.
Information on all temporary bypass authorizations issued under the Regulations will be published in the Registry of Authorizations.
Refusal and revocation
Refusal of temporary bypass authorization
ECCC may refuse to issue a TBA if:
- the bypass would result in adverse effects on fish, fish habitat or use of fish by persons that cannot be mitigated
- the TBA application is not submitted in the required timeline (21, 45 or 90 days before the start of the bypass)
- the information provided in the application is false or misleading
- the application does not contain the required information
Revocation of a temporary bypass authorization
A TBA may be revoked by ECCC after it has been issued if:
- the information contained in the temporary bypass authorization application is false or misleading
- the TBA holder has failed to comply with the conditions set out in the authorization or the compliance obligations
- new information indicates that the authorized deposit had or is likely to have an effect on fish, fish habitat or the use of fish by persons that is more adverse than the effects that were anticipated when the authorization was issued
ECCC must provide in writing the reasons for the proposed revocation to the TBA holder. Additionally, the TBA holder must be given the opportunity to discuss the proposed revocation in writing.
Annex: application examples
The period (start and end date) of the authorization
- Work will be performed on a wastewater system over a 2-week period in September 2024
- The start date is September 1, 2024 and the end date is September 14, 2024
The approximate duration of the deposit (in hours)
- Work at a mechanical treatment plant is being performed to clean out the wet well of the facility: the plant will be put into bypass on Monday and will be put back in operation on Friday
- This bypass will occur continuously over 5 days, so the approximate duration of this deposit would be 120 hours
The duration of the work (in hours)
- Work is being performed on a lagoon system for 3 months, however a bypass will only occur for 2 weeks while a lagoon cell is drained
- Duration of work in hours is 2184 hours (3 months), and
- Duration of the deposit in hours is 336 hours (2 weeks)
The estimated volume (m3) of the deposit and an explanation of how the volume was estimated
Example 1
- Work is being performed at a pumping station
- Based on historical data at this period of the year, it is expected that 3,000 m3 of wastewater will need to be diverted
- To be conservative, the applicant adds a 15% buffer to the expected value. This 15% corresponds with the 10-year peak they have measured at the pumping station
- Estimated volume of the deposit: 3,450 m3
Explanation: 3,000 m3 expected based on historical data plus a conservative buffer of 15% (450 m3)
Example 2
- Work is being performed at a mechanical plant that has 2 treatment trains
- One treatment train will be taken offline to perform the work, while the other will remain operational
- The estimated flow through each treatment train is 20,000 m3 per day (40,000 m3 total for the entire system per day)
- Estimated volume of the deposit: 20,000 m3 x # of days work is performed
Explanation: 20,000 m3 per day based on normal capacity. Expect to divert as much flow as possible to functional treatment train. Undertreated wastewater will be mixed with treated wastewater before deposit.
Example 3
- Work is being performed at a pumping station
- For the duration of the work, a temporary pipe will be installed that is 70% of the normal capacity
- The temporary pipe will be able to handle base flows, however, a deposit of untreated wastewater will occur if there is a large rainfall event
- Estimated volume of the deposit: 50 m3
Explanation: Based on historical flow volumes, the temporary pipe should be able to handle all flows while the work is performed. Factoring in expected rainfall at the time of year, only 50 m3 of untreated wastewater is expected to be deposited if there is a large rainfall event.
A description of the treatment, if any, that will be applied to effluent prior to deposit, and whether deposits will be caused by precipitation events occurring during a period of reduced capacity
Example 1
- Work is being performed at a mechanical treatment plant: the secondary clarifiers will be taken offline for maintenance
- Effluent will still be treated by the preliminary bar screens and primary clarifiers
- Based on intermediary samples, the effluent quality is expected to be approximately 50 mg/L SS and 50 mg/L CBOD
Example 2
- Work is being performed at a pumping station and a temporary pipe is put in place
- If it rains, effluent may be bypassed and deposited into the receiving environment. As a conservative estimate, it is expected bypassed wastewater will be a mixture of 50% rainwater and 50% wastewater
- Based on raw wastewater influent quality data, this ratio would result in bypassed effluent quality to be approximately 100 mg/L TSS and 100 mg/L CBOD
An explanation of how the bypass is designed to minimize the volume of effluent deposited and the concentrations of deleterious substances
- Work is being performed during the night to ensure the lowest volume of effluent is bypassed
- Preliminary treatment will be maintained such that debris and large solids are removed
The point(s), in latitude and longitude, from where effluent will be deposited
- Select final discharge point(s) and overflow point(s) as applicable
A description of the water or place where bypass will be deposited
- The release occurs into Y river that has a flow rate at the bypass location of 100 m³/s
If bypass is at an overflow point, a statement indicating whether the water or place the overflow point releases into regularly receives wastewater under normal conditions
- X overflow point where the bypass is occuring is located downstream of the final discharge point of the wastewater system
A description of the work and an explanation of why it is necessary to bypass at least one of the treatment processes normally applied to the wastewater in the system
- This work requires changes to the headworks of the mechanized treatment system
- Due to the configuration of the system and lack of redundancy, a bypass is required to complete this work
An explanation of how the bypass follows the previously declared plan to reduce bypasses over time (if required)
- This work is part of our previously declared plan to reduce combined sewers in the collection network and add redundancies to our system
- This work falls under Phase X of the plan that is publicly available on our website since January YYYY
- So far, timelines in the plan are still expected to be met
A list of measures that will be implemented to avoid or mitigate the adverse effects of the bypass on fish, fish habitat or the use of fish by persons
Examples of measures that could be provided:
- installing temporary treatment systems, pumps and/or piping
- continuing to provide treatment through other treatment processes
- phasing work to allow for the most treatment capacity
- sampling effluent and/or the receiving environment for substances of concern
- avoiding a period when the receiving environment is more sensitive (that is, fish spawning)
- sending residents a Public Service Announcement to conserve water
The timing for the proposed work was chosen specifically to reduce the risk of harm.
A description and the results of notifications to and engagements with members of the public, communities or Indigenous governing bodies that may be impacted by the proposed bypass
- The applicant has notified nearby communities and the local Indigenous groups via email
“We notified these groups by email as this is how we have previously committed to communicate with them. We notified these groups as they are within a 25 km radius of the final discharge point and they may utilize the waterbody during the bypass. We provided all groups with a summary of the work being performed, and the reason the bypass is necessary. We included the estimated duration and effluent quality of the bypass. We noted the exact timing of each shutdown will be subject to regulatory approvals, equipment delivery, and contractor availability, and that an up-to-date notification would be posted on our website. To date, none of the groups voiced any concerns regarding the work, however we will email ECCC if we receive any responses.”
For additional information
Visit the Wastewater website.
If the information you need is unavailable on our website, please contact Environment and Climate Change Canada (ECCC) at eu-ww@ec.gc.ca.
Disclaimer
This information does not in any way supersede or modify the Wastewater Systems Effluent Regulations or the Fisheries Act, or offer any legal interpretation of those Regulations or Act. Where there are any inconsistencies between this information and the Regulations or Act, the Regulations or Act take precedence, respectively. A copy of the Regulations is available on line.
