Code of Practice for the Environmental Management of Road Salts

Annual overview of data reported for 2019 to 2023 in the context of national targets

Download the alternative format
(PDF format, 1.82 MB, 34 pages)

Overview

In December 2014, Environment and Climate Change Canada (ECCC) set seven Performance Indicators and National Targets in order to monitor the effectiveness of the Code of Practice for the Environmental Management of Road Salts (the Code).

Federal, provincial, municipal, and private road organizations that adopted the Code reported the following results (Figure 1) which are compared with the National Targets (1-6) set for 2019 (Target #7 is set for 2024). Data submitted in annual reports is compiled and analyzed for a winter period, which is generally from November of one year to April of the next year. Throughout the report, a reporting year is represented by the final year of that winter (e.g. 2023 represents the winter starting in 2022 and ending in 2023). Note that some year-to-year variation in results exists due to variance in the number of reports submitted annually.

Figure 1: Summary results for performance and comparison to national targets

Figure 1: Summary results for performance and comparison to national targets
Long description

This horizontal bar graph presents the 7 national targets and the results against those targets for the following years:

  • 2014
  • 2019
  • 2020
  • 2021
  • 2022
  • 2023

Targets 1 to 7 go from top to bottom. Note that there are two indicators for Target 6: 6a and 6b. For each target, 6 horizontal bars are grouped. The bottom bar represents the target itself.  The other 6 bars are results for:

  • 2014
  • 2019
  • 2020
  • 2021
  • 2022
  • 2023
  • Target 1: Number of submissions (percentage of 220)
    The target is set at 100% by 2019. Results are:
    • 114% in 2023
    • 103% in 2022
    • 100% in 2021
    • 99% in 2020
    • 98% in 2019
    • 92% in 2014
  • Target 2: Annual review of salt management plans
    The target is set at 100% by 2019. Results are:
    • 52% in 2023
    • 57% in 2022
    • 57% in 2021
    • 56% in 2020
    • 62% in 2019
    • 60% in 2014
  • Target 3: Salt storage – Road salts
    The target is set at 100% by 2019. Results are:
    • 96% in 2023
    • 100% in 2022
    • 100% in 2021
    • 100% in 2020
    • 97% in 2019
    • 100% in 2014
  • Target 4: Salt storage – Treated abrasives
    The target is set at 75% by 2019. Results are:
    • 63% in 2023
    • 73% in 2022
    • 72% in 2021
    • 69% in 2020
    • 72% in 2019
    • 67% in 2014
  • Target 5: Salt application – Electronic controllers
    The target is set at 95% by 2019. Results are:
    • 89% in 2023
    • 93% in 2022
    • 94% in 2021
    • 95% in 2020
    • 93% in 2019
    • 93% in 2014
  • Target 6a: Salt application – Organizations using pre-wetting or pre-treated salt
    The target is set at 95% by 2019. Results are:
    • 66% in 2023
    • 67% in 2022
    • 66% in  2021.
    • 69% in 2020
    • 65% in 2019 and 2014.
  • Target 6b: Salt application – Vehicles equipped for pre-wetting
    Target is set at 75% by 2019. Results are:
    • 77% in 2023
    • 68% in 2022
    • 68% in 2021
    • 66% in 2020
    • 65% in 2019
    • 67% in 2014.
  • Target 7: Salt vulnerable areas identified & action plan
    The last target is set at 95% by 2024. Results are:
    • 30% in 2023
    • 36% in 2022
    • 32% in 2021 and 2020
    • 35% in 2019
    • 22% in 2014

Highlights*: 2023 reported data in the context of National Targets

Results reported for winter 2022-2023:

* See Annex 1 for highlights of past reporting seasons

Background

The Code of Practice for the Environmental Management of Road Salts (the Code) was developed in 2004 to assist municipal and provincial road organizations to better manage their use of road salts in a way that reduces the harm to the environment while maintaining roadway safety. The Code recommends that road organizations that use over 500 t/year of salt or who have salt vulnerable areas in their territory review their existing winter maintenance operations to improve practices and reduce adverse impacts of salt releases in the environment. This includes the development and implementation of salt management plans identifying actions they will take to improve practices in salt storage, use of salts on roads, snow disposal, and protection of salt vulnerable areas. In addition, the Code recommends that road organizations provide an annual reportFootnote 1 on the progress achieved.

Of note, Quebec launched the Strategy for the Environmental Management of Road Salts in 2010. Administrations that manage and maintain roads in Quebec are invited to participate in the Strategy on a voluntary basis. As a result, the federal Code is not implemented in Quebec. However, the general objectives of the Code and of the Strategy are similar. In 2019, the province conducted a five-year study during which an online questionnaire was made available to municipalities to learn about best management practices in place. Sixty-four municipalities responded to the questionnaire. The survey results are published on the Quebec Strategy website (French only).

Results

ECCC published the Five-year Review of ProgressFootnote 2 (2005–2009), available online, to measure the effectiveness of the Code in April 2012. Based on the review, ECCC recommended maintaining the Code and encouraged road organizations to continue improving their salt management. However, at the time of the first review, the lack of targets created challenges in determining whether the objective of the Code had been achieved. It was recommended that the list of performance indicators for future evaluations be examined to ensure that they reflect key components of the Code and current techniques in winter maintenance.

In 2014, ECCC published Performance Indicators and National Targets for the Code of Practice for the Environmental Management of Road Salts for the implementation of best practices so that progress can be tracked and the success of the Code can be evaluated. The main objective for setting national targets was to increase environmental protection. All road organizations are expected to reach a minimum level of progress in the implementation of best practices to prevent and reduce negative impacts from road salts. National targets help to monitor progress in specific areas of the Code and form the basis for the second Review of Progress (2014-2019)  Review of Progress: Code of Practice for the Environmental Management of Road Salts 2014 to 2019 evaluating the effectiveness of the Code.Footnote 3

There are seven performance indicators (with six targets set for 2019 and one for 2024) that fall under four main activities of the Code (adoption of the Code, salt storage, salt application and salt-vulnerable areas) as summarized and illustrated above (Figure 1). The following results are based on the analysis of data reported annually by road organizations under the Code for 2019-2023. Throughout this report, 2014 data represent the baseline when analysis was initiated against the targets. Data prior to 2019 can be found in the Review of Progress reports mentioned above.

Because reporting is voluntary, there can be significant data variation from year to year as the same organizations may not report annually. Please note that one large organization that reported late in 2022 was added to the 2022 analysis for this year and all graphs and tables were readjusted accordingly. Annex 3 presents additional information on reported use of de-icers (salt, liquids and abrasives) and salted road length data.

Performance indicator 1: “Submission of annual reports” represents the number of road organizations reporting regularly (Figure 2). The purpose of this indicator is to increase the level of implementation of the Code and best practices in road salt management. Overall, the number of submissions has increased since 2014 and exceeded the target in 2023 with 250 organizations reporting. Table 1 also presents the breakdown of organizations by type that have reported for 2019-2023. Annex 2 presents the list of road organizations that reported in 2023.

Figure 2: Number of reports submitted by road organizations to Environment and Climate Change Canada

Figure 2: Number of reports submitted by road organizations to Environment and Climate Change Canada
Long description

This vertical bar graph presents the number of reports submitted by road organizations in:

  • 2014
  • 2019
  • 2020
  • 2021
  • 2022
  • 2023

A horizontal red line through the graph identifies the target of 220 reports submitted annually by the target year of 2019. The data is:

Year Total
2014 202
2019 216
2020 218
2021 219
2022 227
2023 250
Table 1: Breakdown of the type of road organizations that have reported under the Code for winter seasons 2019 through 2023
Type of road organization 2014 baseline 2019 2020 2021 2022 2023
Provinces and territories 8 9 9 8 7 9
Municipalities 180 189 194 195 203 226
National parks and other federal organizations 10 11 10 11 11 11
Private organizations 4 7 5 5 6 5
Total number of reporting organizations 202 216 218 219 227 250

Performance indicator 2: “Annual review of salt management plan” represents the percentage of road organizations that annually review their salt management plan (SMP) when compared to all organizations that report under the Code. (Figure 3). The objective of this indicator is to ensure that planning is current and allows for continuous improvement. Road organizations should revisit their SMP at the end of each winter in order to identify shortcomings, issues, and areas where improvements are needed prior to the start of the next winter season. In 2023, the target of 100% was not met since only 52% of organizations reported conducting an annual review of their SMP. It is also important to note that 24% of reporting organizations either do not have a complete SMP or are unsure whether their SMP covers all elements as described in the Code.

Figure 3: Percentage of road organizations that review their SMP and the percentage of organizations that report having an SMP

Figure 3: Percentage of road organizations that review their SMP and the percentage of organizations that report having an SMP
Long description

This vertical bar graph presents two bars, one normal and one stacked, per year for:

  • 2014
  • 2019
  • 2020
  • 2021
  • 2022
  • 2023

The first, normal bars, represent the percentage of organizations that reported conducting an annual review of their salt management plan (SMP) against Target 2. Target 2 is 100% of all organizations reviewing their plans by 2019 and is represented by a horizontal red line through the graph. The second, stacked bars, demonstrate:

  • the percentage of organizations that reported having an SMP
  • the percentage of organizations that do not have an SMP
  • the percentage of organizations that are not sure about having an SMP.

The data is:

Year Target #2: % of organizations that performed an annual review of their SMP % of organizations that are not sure about having a complete SMP % of organizations that don’t have a complete SMP % of organizations that reported having a complete SMP
2014 60% 2% 8% 90%
2019 62% 5% 15% 80%
2020 56% 5% 13% 83%
2021 57% 4% 14% 82%
2022 57% 6% 17% 77%
2023 52% 4% 20% 76%

Performance indicator 3: “Storage of road salts” represents the percentage in tonnes of road salts stored under a permanent roof and on impermeable pads (Figure 4). The objective of this indicator is to ensure that road organizations have committed to managing their material storage facilities and that best practices are applied at point sources to prevent the release of salt to the environment. In 2023, the target of 100% was almost met since 96% of reported road salts were stored under a permanent roof and on impermeable pads. The 4% decline from last year is partly attributed to an organization reporting that a large portion of salt is covered by a tarp rather than a permanent roof who did not report in 2022.

Figure 4: Percentage of road salts stored under a permanent roof and on impermeable pads

Figure 4: Percentage of road salts stored under a permanent roof and on impermeable pads
Long description

This vertical bar graph presents the percentage of salts adequately stored under a roof and on an impermeable surface against Target 3 in:

  • 2014
  • 2019
  • 2020
  • 2021
  • 2022
  • 2023

Target 3 is 100% of salts adequately stored by 2019 and is represented by a horizontal red line through the graph. The percentages of salt adequately stored under a roof and on an impermeable surface are:

  • 100% in 2014
  • 97% in 2019
  • 100% in 2020, 2021 and 2022
  • 96% in 2023

Performance indicator 4: “Storage of treated abrasives” represents the percentage in tonnes of treated abrasives (blended sand and salt) that are stored under cover, either under a tarp or under a permanent roof (Figure 5). The objective of this indicator is to ensure that road organizations cover their treated abrasives in storage facilities and that best practices are applied at point sources to prevent the release of salt to the environment. In 2023, the target of 75% was not met with 63% of treated abrasives being reported as covered by tarp or permanent roof. The 10% decline of covered abrasive from 73% in 2022 to 63% in 2023 is partly attributed to an organization reporting no coverage of abrasives who did not report in 2022.

Figure 5: Percentage of treated abrasives covered by tarp or covered by permanent roof

Figure 5: Percentage of treated abrasives covered by tarp or covered by permanent roof
Long description

This stacked histogram presents the percentage of treated abrasives covered by a tarp or by a permanent roof against Target 4 in:

  • 2014
  • 2019
  • 2020
  • 2021
  • 2022
  • 2023

Target 4 is 75% of treated abrasives covered by 2019 and is represented by a horizontal red line through the graph. These results include the percentage of treated abrasives covered by a tarp and the percentage covered under a permanent roof. Percentages for these years are:

  • 66% covered by permanent roof and 1% covered by a tarp for a total of 67% for 2014
  • 72% covered by permanent roof and less than 1% covered by a tarp for a total of 72% for 2019
  • 67% covered by permanent roof and 2% covered by a tarp for a total of 69% for 2020
  • 70% covered by permanent roof and 2% covered by a tarp for a total of 72% for 2021
  • 70% covered by permanent roof and 3% covered by a tarp for a total of 73% for 2022
  • 62% covered by permanent roof and 1% covered by a tarp for a total of 63% for 2023

Performance indicator 5: “Groundspeed electronic controllers” represents the percentage of total vehicles equipped with groundspeed electronic controllers when compared to the total number of vehicles assigned to solid salt application (Figure 6). The objective of this indicator is to ensure that salt is applied at a proper rate regardless of the speed of the truck being used to spread the salt. Also, to ensure that salt stops discharging when the truck stops. Over time, use of this technology is expected to become a core practice for all organizations to optimize the use of salt. In 2023, the target of 95% was almost met with 89% of organizations reporting solid salt application vehicles equipped with electronic controllers. The result for 2022 has been revised downward to 93% from 99% because an error was discovered in the analysis and a late 2022 report was added to the analysis for this year.

Figure 6: Percentage of vehicles equipped with groundspeed electronic controllers

Figure 6: Percentage of vehicles equipped with groundspeed electronic controllers
Long description

This vertical bar graph presents the percentage of vehicles equipped with groundspeed electronic controllers against Target 5 in:

  • 2014
  • 2019
  • 2020
  • 2021
  • 2022
  • 2023

Target 5 is 95% of vehicles equipped by 2019 and is represented by a horizontal red line through the graph. The percentages of vehicles equipped with groundspeed electronic controllers are:

  • 93% in 2014
  • 93% in2019
  • 95% in 2020
  • 94% in 2021
  • 93% in 2022
  • 89% in 2023

Performance indicator 6: “Optimization of salt application” indicates if organizations are adopting practices that enhance their salt application techniques to optimize their use of salt. This can be accomplished either by using pre-wetting and/or pre-treated salts (Figure 7) or by increasing their pre-wetting capacity (Figure 8). The objective of this indicator is to ensure that organizations are using advanced technologies such as pre-wetting to reduce the use of salts and pre-treated materials. These technologies are proven to be a cost-effective alternative to road salts with similar results. Target #6a is calculated by comparing the number of organizations that reported using pre-wetting or pretreated salts to the total amount of organizations that reported. Target #6b is calculated by comparing the reported number of vehicles with pre-wetting technologies to the reported total number of vehicles assigned to solid salt applications from organizations that reported equipping at least one vehicle for prewetting. In 2023, target 6a of 95% was not met since only 66% of organizations reported adopting pre-wetting and pre-treating methods for salt application optimization. However, in 2023, target 6b of 75% was met since 77% of reported vehicles were equipped for pre-wetting.

Figure 7: Percentage of road organizations using pre-wetting or pre-treated salts

Figure 7: Percentage of road organizations using pre-wetting or pre-treated salts
Long description

This vertical bar graph presents the percentage of organizations using pre-wetting or pre-treated salt against Target 6a in:

  • 2014
  • 2019
  • 2020
  • 2021
  • 2022
  • 2023

Target 6a is 95% of organizations use pre-wetted and pre-treated salts by 2019 and is represented by a horizontal red line through the graph. The percentages of organizations using pre-wetting or pre-treated salt are:

  • 65% in 2014
  • 65% in 2019
  • 69% in 2020
  • 66% in 2021
  • 67% in 2022
  • 66% in 2023

Figure 8: Percentage of vehicles equipped for pre-wetting

Figure 8: Percentage of vehicles equipped for pre-wetting
Long description

This vertical bar graph presents the percentage of vehicles equipped for pre-wetting against Target 6b in

  • 2014
  • 2019
  • 2020
  • 2021
  • 2022
  • 2023

Target 6b is 75% of vehicles equipped for pre-wetting by 2019 and is represented by a horizontal red line through the graph. The percentages of vehicles equipped for pre-wetting are:

  • 67% in 2014
  • 65% in 2019
  • 66% in 2020
  • 68% in 2021
  • 68% in 2022
  • 77% in 2023

Performance indicator 7: “Salt-vulnerable areas” indicates if organizations have identified salt vulnerable areas (SVAs) and if an action plan has been prepared with the purpose of protecting those areas that are sensitive to road salts. Figure 9 presents the percentage of reporting road organizations that have identified SVAs. Figure 9 also presents the percentage of road organizations that have met the performance indicator (both identifying vulnerable areas and preparing action plans). In 2023, the target percentage of 95% was not met since only 50% of organizations reported having an inventory of SVAs and only 30% reported having both an inventory and an action plan to address the SVAs.

Figure 9: Percentage of road organizations that have identified salt vulnerable areas and prepared an action plan

Figure 9: Percentage of road organizations that have identified salt vulnerable areas and prepared an action plan
Long description

This vertical bar graph presents the percentage of organizations that have identified salt vulnerable areas (SVAs) and prepared an action plan against Target 7 in:

  • 2014
  • 2019
  • 2020
  • 2021
  • 2022
  • 2023

Target 7 is 95% of organizations have identified salt vulnerable areas (SVAs) and prepared an action plan by 2024 and is represented by a horizontal red line through the graph. The percentages of organizations that did an inventory of SVAs are:

  • 43% in 2014
  • 49% in 2019
  • 51% in 2020
  • 50% in 2021
  • 54% in 2022
  • 50% in 2023

The percentages of organizations that did an inventory of SVAs and prepared an action plan are:

  • 22% in 2014
  • 35% in 2019
  • 32% in 2020
  • 32% in 2021
  • 36% in 2022
  • 30% in 2023

Progress towards the National Targets

Setting national targets offers transparency in the expected performance level from road organizations and provides a basis for conducting future reviews of the effectiveness of the Code. National targets assist road organizations in prioritizing their ongoing efforts in the management of road salts.

The summary of the results of the Code since 2019, Figure 1, shows the progression in achieving national targets over time. Detailed review reports present historical data prior to 2019. While some targets were achieved or close to being achieved (Targets #1, #3, #4 and #6b), others were not (Targets #2, #5 and #6a). The second review of the Code concluded that the Code is still an effective risk management instrument. It recommended continued evaluation against the targets and identified several actions for consideration to improve Code implementation and the environmental management of road salt.

ECCC will continue to promote the implementation of the Code with stakeholders, consisting of provincial and municipal road authorities, federal and provincial governments, related associations, industry, environmental non-governmental organizations, and academics, in order to encourage the implementation of best practices in road salt management and prevent or reduce negative impacts of road salts on the environment.

Contact us

For questions about the Code or for more information about salt management, please contact us.

Annex 1: Highlights of reported data for 2014 to 2022 reporting seasons

Highlights: 2022 Reported Data in the Context of National Targets

Results reported for winter 2021-2022

Highlights: 2021 Reported Data in the Context of National Targets

Results reported for winter 2020-2021:

Highlights: 2020 Reported Data in the Context of National Targets

Results reported for winter 2019-2020:

Highlights: 2019 Reported Data in the Context of National Targets

Results reported for winter 2018-2019:

Highlights: 2018 Reported Data in the Context of National Targets

Results reported for winter 2017-2018:

Highlights: 2017 Reported Data in the Context of National Targets

Results reported for winter 2016-2017:

Highlights: 2016 Reported Data in the Context of National Targets

Results reported for winter 2015-2016:

Highlights: 2015 Reported Data in the Context of National Targets

Results reported for winter 2014-2015:

Highlights: 2014 Reported Data in the Context of National Targets

Results reported for winter 2013-2014:

Annex 2: Road organizations that have reported under the Code of Practice for 2022-2023

Federal organizations:

Provincial and Territorial Organizations:

Municipal Organizations:

Private Organizations:

Annex 3: Reported road salt usage data

Public road organizations participating in the Code also report to ECCC on the total quantity of road salts, abrasives, and liquids used by the organization in the winter maintenance season. In addition, road organizations report to ECCC the length of roads salted by their organization. The total quantity by province of each material used and the total road length salted reported for all road organizations that reported for this winter maintenance season is summarized in Table 3. This represents the total material used and salted road length for road organizations reporting to ECCC. It does not represent the total quantity of deicing materials used or the total length of salted roads in Canada because the Code:

  1. is voluntary
  2. does not apply to road salts used for domestic purposes, or for private or institutional uses
  3. targets organizations that use more than 500 tonnes of road salts per year (although some organizations using less than 500 tonnes also report); and
  4. is not implemented in Quebec since it has its own Strategy for the Environmental Management of Road Salts
Table 3: Number of organizations that reported total salt, liquids, and abrasives quantities as well as total salted road length under the Code for winter 2022-2023
Province Number of organizations that reported Total salt use (tonnes) Total liquids use (litres) Total abrasives use (tonnes) Total road length salted (km)
Alberta 33 370 571 9 305 908 827 752 56 579
British Columbia 27 1 292 635 71 983 490 914 369 14 355
Manitoba 3 90 852 777 544 93 412 794
New Brunswick 18 96 886 2 614 035 13 336 7 408
Newfoundland & Labrador 12 265 331 1 703 104 153 710 25 346
Nova Scotia 12 240 100 26 449 567 28 035 24 256
Ontario 138 2 985 873 41 202 872 975 901 158 156
Prince Edward Island 1 30 517 2 088 977 86 950 1 224
Saskatchewan 4 130 886 1 207 192 69 451 1 877
Yukon 2 6 762 N/A   65 200 1 810
Other federal organizations N/A  N/A N/A N/A N/A
Total 250 5 510 413 157 332 689 3 228 116 291 804
Table 4: Number of organizations that reported total salt, liquids, and abrasives quantities as well as total salted road length under the Code for winter 2021-2022
Province Number of organizations that reported Total salt use (tonnes) Total liquids use (litres) Total abrasives use (tonnes) Total road length salted (km)
Alberta 24 417 394 13 089 162 823 810 61 576
British Columbia 26 889 055 58 302 838 781 204 50 559
Manitoba 2 148 421 379 000 113 536 1 916
New Brunswick 17 219 783 3 065 613 369 331 21 297
Newfoundland & Labrador 6 60 247 1 233 991 10 375 2 422
Nova Scotia 11 294 690 24 740 324 42 022 19 628
Ontario 134 2 539 786 39 297 104 1 111 353 124 012
Prince Edward Island 1 2 750 N/A N/A 118
Saskatchewan 4 137 402 1 084 608 85 555 22 799
Yukon 2 3 491 N/A 69 300 2 900
Other federal organizations N/A N/A N/A N/A N/A
Total 227 4 713 019 141 192 640 3 406 486 307 227
Table 5: Number of organizations that reported total salt, liquids, and abrasives quantities as well as total salted road length under the Code for winter 2020-2021
Province Number of organizations that reported Total salt use (tonnes) Total liquids use (litres) Total abrasives use (tonnes) Total road length salted (km)
Alberta 26 1 116 360 11 395 525 713 916 61 955
British Columbia 25 831 242 57 353 512 785 918 53 482
Manitoba 3 113 273 1 217 533 88 489 17 297
New Brunswick 15 190 196 3 783 672 231 949 21 471
Newfoundland & Labrador 8 63 262 1 496 378 9 376 2 892
Nova Scotia 9 177 435 22 058 402 32 329 17 197
Ontario 128 2 088 323 39 784 058 788 150 103 784
Prince Edward Island N/A N/A N/A N/A N/A
Saskatchewan 3 113 654 413 857 52 453 20 481
Yukon 2 6 099 N/A 66 100 3 000
Other federal organizations N/A N/A N/A N/A N/A
Total 219 4 699 843 137 502 937 2 768 680 301 559
Table 6: Number of organizations that reported total salt, liquids, and abrasives quantities as well as total salted road length under the Code for winter 2019-2020
Province Number of organizations that reported Total salt use (tonnes) Total liquids use (litres) Total abrasives use (tonnes) Total road length salted (km)
Alberta 26 1 170 953 9 942 475 743 339 62 201
British Columbia 26 1 021 173 55 816 117 929 456 55 991
Manitoba 3 93 834 1 777 676 139 878 14 531
New Brunswick 17 279 878 4 112 349 334 335 21 678
Newfoundland & Labrador 8 63 428 1 597 655 8 496 2 290
Nova Scotia 10 295 277 24 329 908 57 541 17 125
Ontario 121 2 781 677 44 790 766 1 024 543 105 392
Prince Edward Island 1 35 469 1 400 000 96 960 4 444
Saskatchewan 4 123 685 504 642 51 525 21 206
Yukon 2 10 793 N/A 94 110 2 540
Other federal organizations N/A N/A N/A N/A N/A
Total 218 5 876 167 144 271 588 3 480 183 245 196

Additional information can be obtained at:

Environment and Climate Change Canada
Public Information Centre
Place Vincent Massey building
351 St-Joseph boulevard
Gatineau Quebec K1A 0H3
Toll free: 1-800-668-6767
Email: enviroinfo@ec.gc.ca

Page details

2025-01-13
