Type of Document

Includes all photographic prints: black-and-white, monochromatic, or colour.


Black and white photo of two figures standing by a stone wall  framed with border and a 10 cm colour scale and the number 0101010101.


  • Keep a border around the document to allow reframing of the document as well as later modifications (e.g., removing the scale and document number).
  • Batch digitization enhances productivity, but does not offer optimal rendering of individual images.
  • For documents larger than the surface of the digital scanner, use the instructions for normal-sized artifact photography.


  1. 300 ppi, with a minimum of 3,000 pixels for the longest dimension (8 x 10, or 1:1 for formats larger than 8 x 10).
  2. Refer to the general guidelines to calculate the number of ppi required for a given dimension.
    Note that it is the original document which measures 8 x 10, not the final digital file.
  3. Digitize in reflective mode.
  4. Select 48-bit mode on the scanner to capture the maximum number of colours. If this option is not available, 24-bit mode is acceptable.
  5. As a point of reference, digitize a colour scale (Kodak Q-14 or Q-60) before each digitization session.
  6. Use a grey background.
    Black and white photo of a man using an agricultural tool in front of a barn with a grey scale and the number: 0101010101.
  7. Digitize the document with a grey or colour scale and, depending on available space, always place it in the same location (ideally lower left).
  8. Colour-balance each image as indicated in the general guidelines. If there is no greyscale reference, balance the levels of white in the brightest zone (D-Max), then balance the black in the darkest zone (D-Min).
  9. Enlarge the frame by one inch at the bottom, and type the document number in black at the lower right (font: Arial, 40 pts.).
  10. Flatten the image (i.e., flatten layers).
  11. Convert in Adobe RGB 1998 profile, 8 bits per channel (total 24 bits), or if the document is black-and-white, save in "Gray Gamma" 2.2, 8 bits.
  12. Save the image as an uncompressed TIFF, named to standards established by the Corporation's Photo Archives.
  13. Produce a JPEG version as described in the general guidelines.
