Latent tuberculosis infection in Peel region, Ontario


Volume 43-5, May 4, 2017: Implementation science


Evaluation of latent tuberculosis infection surveillance in Peel region, Ontario, 2010–2014

JA Majerovich1,2, L Fernandes2, M Varia2*


1 Field Service Training and Response Division, Public Health Agency of Canada, Ottawa, ON

2 Peel Public Health, Mississauga, ON


Suggested citation

Majerovich JA, Fernandes L, Varia M. Evaluation of latent tuberculosis infection surveillance in Peel region, Ontario, 2010–2014. Can Commun Dis Rep. 2017;43(5):114-8.


Background: In Canada, identification and treatment of individuals with latent tuberculosis infection (LTBI) is a key component in preventing the progression of LTBI to active tuberculosis (TB). In Peel region, a large municipality in Ontario where half of the population is foreign-born, LTBI surveillance data are also critical to understanding the local epidemiology of TB.

Objective: To evaluate LTBI surveillance data collected through the integrated Public Health Information System (iPHIS) from 2010 to 2014 by assessing data quality and usefulness and to provide recommendations to improve surveillance for Peel region.

Methods: Using the European Centre for Disease Prevention and Control framework for surveillance evaluation, data quality was assessed based on completeness and validity of key variables in the iPHIS database. Usefulness of surveillance data in informing program decisions was assessed through interviews with stakeholders from Peel Public Health.

Results: Of 6,576 iPHIS records evaluated, data for gender and date of birth were greater than 99% complete, while more than half of the risk factor fields were blank or ‘unknown’. A comparison of 192 paper charts to the corresponding iPHIS record identified coding errors in over 40% of iPHIS risk factor fields. Treatment completion documented in iPHIS (20%) was lower than data obtained from a follow-up telephone survey of cases (50%). Stakeholders found surveillance data to be useful (100%), however, recommendations were made for improvement of data collection and analysis.

Conclusion: Evaluating LTBI surveillance to improve data quality and usefulness for program planning is essential in an era of TB elimination. This evaluation resulted in standardization of data entry processes and continuation of direct follow-up with LTBI clients to confirm treatment completion. Work to understand barriers to treatment initiation and completion is currently underway.


Infection with Mycobacterium tuberculosis can result in latent tuberculosis infection (LTBI) or active tuberculosis (TB) Footnote 1. The progression of LTBI to active TB can be reduced by up to 90% with nine months of preventive treatment Footnote 1Footnote 2. The World Health Organization has identified that better identification and treatment of those with LTBI who are at higher risk of progressing to active TB is integral to the new TB elimination goals Footnote 3. Although Canada has a low incidence of TB overall, rates are higher among sub-populations such as immigrants from countries with high incidence of TB, travellers to these countries and Indigenous Canadians. The Region of Peel is a large municipality in Ontario with a population of 1.4 million. Half (50.5%) of Peel’s population is foreign-born, many from TB-endemic countries. This is higher than the percentage of foreign-born individuals in Ontario (28.5%) Footnote 4. In 2014, the age-standardized active TB incidence rate in Peel was 9.1 per 100,000, compared to 4.0 per 100,000 for Ontario Footnote 5. Approximately 1,200 LTBI cases are reported each year to the local health department, Peel Public Health (PPH) Footnote 6.

Identification and treatment of individuals with LTBI at increased risk of progressing to active TB is a pillar of the strategy to prevent the progression of LTBI to active TB. Canadian Tuberculosis Standards target at least 80% of those LTBI cases that start treatment will complete the required number of doses Footnote 1. Peel LTBI surveillance data are used to monitor treatment completion, identify population groups at higher risk of active disease and evaluate the effectiveness of program interventions.

Despite the importance of surveillance to evaluate the effectiveness of TB prevention and control efforts, there is limited published evidence evaluating LTBI surveillance Footnote 7Footnote 8Footnote 9. The objectives of this study were to evaluate LTBI surveillance data collected through Ontario’s integrated Public Health Information System (iPHIS) by assessing two surveillance attributes—data quality (data completeness and validity) and usefulness, and ) provide recommendations to improve LTBI surveillance in Peel region.

In Ontario, iPHIS is the database used by all public health departments to report information on cases of reportable diseases (including LTBI) to the Ministry of Health and Long-Term Care, as mandated under Ontario’s Health Protection and Promotion Act, R.S.O. 1990 Footnote 10Footnote 11. Data on LTBI cases are passively reported to PPH by local reporting sources such as community clinicians and hospitals. When a case of LTBI is reported to PPH, public health nurses document case information in a paper-based client chart, which is then entered into iPHIS. Surveillance data are routinely analyzed by PPH epidemiologists for programming implications.


The evaluation of the LTBI surveillance system was based on the European Centre for Disease Prevention and Control (ECDC) framework Footnote 12. This framework was chosen because of its focus on data quality, which was a primary objective of the surveillance evaluation. The surveillance attributes that were assessed are summarized in Table 1. Internal completeness, and internal and external validity were selected because program decisions are based on the information available in iPHIS. Usefulness was chosen to identify surveillance strengths and opportunities for improving the use of data for public health action.

Table 1: Latent tuberculosis infection evaluation surveillance attributes
Attribute Definition
Internal completeness Proportion of complete data fields within the database
Internal validity Extent of errors within the surveillance system, e.g. coding errors in translating from one level of the system to the next
External validity Whether information recorded about cases is correct when compared to an external database or ‘gold standard’
Usefulness Whether surveillance results are used for public health action

Internal completeness: Internal completeness was measured by calculating the proportion of missing (i.e., blank and ‘unknown’) responses for selected variables. These include: client demographics (date of birth, gender, origin), risk factors (behavioural social factors, exposure settings, medical risk factors) and treatment variables (treatment start date and treatment end date as specified by the client or their physician). Relevant data fields from all Peel LTBI cases reported from 2010 to 2014 were extracted from the iPHIS database using Cognos ReportNet and analyzed using Stata 14.

Internal validity: Using PPH’s paper-based charts for LTBI cases as the standard, internal validity was assessed by comparing data in iPHIS with the paper chart for selected variables. Due to the large number of LTBI cases, a sample size of 203 LTBI cases from 2014 was calculated based on a 95% confidence level, a population size of 1,157, a hypothesized 20% frequency of the outcome factor in the population and a design effect of 1.0 for a random sample ( Every fifth chart from 2014 was sampled and 192 charts were assessed because some of the charts could not be immediately located.

External validity: External validity was assessed by comparing LTBI treatment completion data from 2010 to 2014 in iPHIS to treatment completion data obtained from active telephone follow-up of LTBI cases. The telephone survey of LTBI cases was conducted by PPH staff from July 2015 to April 2016 with cases known to have started treatment. Given the length of treatment for LTBI is typically nine months for the first-line regimen Footnote 1 the 208 clients contacted were likely diagnosed with LTBI in 2014 and 2015.

Usefulness: Eight semi-structured interviews were conducted in person with internal stakeholders from PPH to assess the usefulness of LTBI surveillance for informing public health action. Stakeholders were chosen to represent a range of viewpoints, from frontline public health nurses who are directly involved in the system’s operation to public health decision-makers, including the medical officer of health. Stakeholders were asked about actions taken as a result of surveillance data, surveillance challenges and opportunities. Responses were recorded in text format and data analysis was performed by three PPH epidemiologists (JAM, MV and the TB epidemiologist) who first assessed themes individually and then came to consensus regarding common themes using a facilitated small group method.


Internal completeness: Of 6,576 LTBI cases, data for gender and date of birth were almost 100% complete (Table 2). Of LTBI cases who had missing or ‘unknown’ origin (n=1,716), 0.1% had birth province documented and 1.9% had immigration birth country documented. Completeness was suboptimal for the data fields for treatment end date (64.6% incomplete), treatment start date (52.3% incomplete) and risk factor (54.7% incomplete).

Table 2: Internal completeness of latent tuberculosis infection data fields
Variable Total number of records Number (%) of records with missing data field Number (%) of records with ‘unknown’ data field Number (%) of records with complete data
Date of birth 6,576 0 (0) 0 (0) 6,576 (100)
Gender 6,576 0 (0) 46 (0.7) 6,530 (99.3)
Origin 6,576 7 (0.1) 1,709 (26.0) 4,860 (73.9)
Risk factor 6,576 270 (4.1) 3,326 (50.6) 2,980 (45.3)
Treatment start date 6,576 3,436 (52.3) 0 (0) 3,140 (47.7)
Treatment end dateTable 2 - Footnote 1 3,140 2,030 (64.6) 0 (0) 1,110 (35.4)

Internal validity: Except for risk factor data, all variables assessed had high internal validity (>94%) (Table 3). Fifty-seven percent of responses for risk factor in iPHIS did not match the paper-based chart. Of those records that did not match on medical risk factor, 46.3% had ‘unknown’ medical risk factor entered in iPHIS, whereas in the chart, the client’s physician had specifically documented that there were no medical risk factors. In addition, 10.9% of the charts reviewed had a medical risk factor documented in the paper chart that was not entered in iPHIS.

Table 3: Internal validity of latent tuberculosis infection data fields (N=192Table 3 - Footnote 1)
Variable Number (%) of records with valid data
Gender 191 (99.5)
Date of birth 190 (99.0)
Treatment outcome status 190 (99.0)
Reason treatment ended 189 (98.4)
Immigration birth country 188 (97.9)
Treatment end date 185 (96.4)
Treatment start date 181 (94.3)
Risk factor 110 (57.3)

External validity: Active follow-up by telephone with 208 LTBI cases that had no recorded treatment end date in iPHIS identified a treatment completion rate of 50%. This is compared to treatment completion documented in iPHIS which was approximately 20% from 2010 to 2013 (Table 4). In 2014, treatment completion for LTBI in iPHIS was 28%, however, this includes clients that were part of the telephone survey where the treatment end date was subsequently entered into iPHIS. No new intervention was instituted that could account for the increase.

Table 4: External validity of latent tuberculosis infection treatment completion rates
Year Total number of cases that started treatment Number (%) of cases with treatment completion in iPHIS
2010 723 141 (19.5)
2011 698 149 (21.3)
2012 589 118 (20.0)
2013 602 115 (19.1)
2014 528 149 (28.2)

Usefulness: The response rate for the key stakeholder interviews was 100%. Overall, surveillance data were found to be useful for program planning and implementation (100%). However, three themes emerged with some recommendations to improve usefulness of LTBI surveillance data:

  1. Passive surveillance which relies on clinicians to submit completed forms is a barrier to completeness of information on risk factors and treatment completion. One interviewee stated that “data is as good (complete) as what we get from doctors…we see data gaps in risk factors and treatment completion”.Electronic medical record alerts were suggested as one strategy to improve reporting among community clinicians. Another respondent elaborated on the consequences of incomplete data in terms of the ability to develop effective interventions for prevention and control. “(There are) gaps in physician reporting requirements and completion of the surveillance forms…we don’t know who to target and monitor more closely.”
  2. Surveillance data are used by PPH staff for public health action. One interviewee stated, “A surveillance report showed high rates of active TB and a low rate of reported LTBI in one municipality of Peel…so the TB nurses did physician outreach on who to screen to improve LTBI diagnosis” (in an effort to detect and treat LTBI cases to prevent progression to active TB).
  3. Usefulness of LTBI surveillance data for program action can be refined with improved data analysis and collection of data specific to the local context.One interviewee asked, “How effective are our data in telling the LTBI story in Peel? Do Peel’s active TB cases arise from known LTBI cases (where there was an opportunity to intervene)?”Another respondent stated that current policies for screening immigrants are resource intensive for “not a lot of transmission risk (in Peel); we need to tailor TB interventions to the local context.”


The evaluation of LTBI surveillance in Peel identified high data completeness (>99%) for demographic variables, high data validity (>99%) for most fields in iPHIS and LTBI treatment completion that is higher than what was documented in iPHIS. However, less than half of risk factor data in iPHIS is complete and just over half is valid, highlighting some of the limitations of the iPHIS system and the need to modify data entry and case management processes. Nonetheless, LTBI surveillance in Peel has proved useful for informing public health action, such as physician outreach interventions.

Several opportunities were identified to improve data quality. With 54.7% of LTBI risk factor data missing or ‘unknown’, next steps include standardizing processes for data entry. Because there is no field to capture ‘no medical risk factors’, this information was recorded in iPHIS as ‘unknown’ explaining in part the reason for this discordance. However, 10.9% of LTBI cases also had a documented medical risk factor in the paper chart that was not entered in iPHIS. The accuracy of risk factor data in iPHIS is particularly relevant from a cost-benefit perspective as resources could be mobilized to follow-up LTBI cases that are at increased risk of progressing to active TB (e.g. because of a medical risk factor). Valid and complete risk factor data are required to identify population groups at increased risk and in need of targeted measures.

The high percentage (64.6%) of missing or ‘unknown’ treatment end date data is being addressed. The current passive physician reporting system contributes to the low percentage of recorded LTBI treatment completion. Active telephone follow-up of LTBI clients by public health staff better captures treatment completion data; however, with over 1,200 LTBI cases reported to Peel annually, this may not be sustainable. In the longer term, technology solutions that facilitate clinician reporting of risk factors and treatment completion to public health are being explored. Engaging community clinicians in an external stakeholder consultation would also be worthwhile to determine how to best address the challenges they face in reporting LTBI data.

One strength of this evaluation is that it provides direction to improve the usefulness of surveillance data, such as specific analyses to better understand the Peel LTBI population. For example, internal stakeholders discussed the public health role for management of LTBI detected during TB screening of new immigrants to Canada. The emergence of this theme from the interview data led Peel to re-analyze TB data from 2015, which identified that 23% of foreign-born TB cases are diagnosed within one to five years of immigrating to Canada, compared to 40% diagnosed with active TB after living in Canada for more than 15 years (unpublished). While this may be due to several reasons (e.g. development of chronic conditions which increase the risk of reactivation, or travel back to country of birth resulting in re-exposure to TB), the greatest risk for TB among Peel cases may not be at the time individuals immigrate to Canada when public health currently intervenes. Additional analyses to examine the differences between LTBI clients that complete treatment and those who do not is also underway.

Two limitations influence the evaluation results. Ideally, the assessment of external validity requires that surveillance data would be measured against a ‘gold standard’. The authors of this article did not have access to LTBI patient records kept by community clinicians, therefore a telephone survey of LTBI cases to determine whether treatment was completed was used as the ‘gold standard’ comparison. While PPH telephone follow-up with a sample of LTBI cases indicated that treatment completion was under-reported in iPHIS, the extent of under-reporting could not be quantified. However, there is also a risk that LTBI cases may not be aware that they did not complete the full nine months of treatment, so self-reporting on treatment completion may have been an overestimate. The second limitation was the inability to assess external completeness (or sensitivity), i.e., the extent to which Peel LTBI cases are captured by the current surveillance system. A study that evaluated LTBI surveillance in Massachusetts observed that substantial under-ascertainment of LTBI was likely and that mandatory reporting does not appear sufficient for LTBI detection Footnote 7. The authors suggest that enhanced targeted testing, active LTBI surveillance or laboratory-based surveillance may be needed to eliminate TB in the United States. These strategies may have applicability in Peel region as well.

LTBI surveillance data that are of high quality and useful for informing public health action are essential to TB prevention and control. Canadian TB standards target at least 80% treatment completion in LTBI cases that start treatment. In this evaluation telephone follow-up of Peel LTBI cases identified a treatment completion rate of 50%, but this rate remains below the national target. While PPH continues active surveillance to ascertain true LTBI treatment completion rates, work to understand barriers to treatment initiation and completion in Peel region is also underway. It is anticipated that this surveillance evaluation will have relevance for other jurisdictions in Canada and other developed countries, particularly with sub-populations that have higher rates of active TB. Evaluating and improving LTBI surveillance is fundamental to advancing TB elimination efforts in Canada.

Authors’ statement

  • JAM – conceptualization, methodology, formal analysis, investigation, writing-original draft, review and editing
  • LF – conceptualization, writing-review and editing
  • MV – conceptualization, methodology, writing-review and editing, supervision

Conflict of interest



The authors would like to thank the community clinicians in Peel who reported LTBI data. From Peel Public Health, we thank the TB program staff, M Baltazar, S Raju, G Kujbida, M Horn, A Richards, R Strange, I Mogck, K Bingham and M Hau. From the Public Health Agency of Canada, we thank FW Tremblay, D Paquette, M Wood, N Gilbert, M McGuire, Field Service Training Response and Canadian Field Epidemiology Program Cohort 41.


This work was supported by the Public Health Agency of Canada’s Canadian Field Epidemiology Program and Peel Public Health.
