Reducing manure methane emissions (protocol version 1.0)

Foreword

Canada’s Greenhouse Gas (GHG) Offset Credit System is established under Part 2 of the Greenhouse Gas Pollution Pricing Act to provide an incentive to implement projects that result in domestic GHG reductions that would not have been generated in the absence of the project, that go beyond legal requirements and that are not subject to federal or provincial pricing mechanisms for GHG emissions.

Canada’s GHG Offset Credit System consists of:

Only projects following a federal offset protocol included in the Compendium and meeting all requirements outlined in the Regulations can generate GHG reductions for which federal offset credits may be issued under the Regulations.

Download the alternative format
(PDF format, 1215 KB, 65 pages)

1.0 Introduction

Methane emissions from livestock manure are primarily generated by anaerobic decomposition of organic matter in liquid manure in an anaerobic storage structure. Implementation of manure treatment systems (MTS) for liquid manure can reduce these methane emissions by reducing the amount of manure methane produced during storage.

The Reducing Manure Methane Emissions federal offset protocol is intended for use by a proponent implementing a project that treats eligible manure with one or more eligible MTS in order to generate greenhouse gas (GHG) emission reductions for which federal offset credits may be issued under the Canadian Greenhouse Gas Offset Credit System Regulations (the Regulations). The following are eligible project MTS:

The proponent must follow the quantification methodology and requirements set out in this protocol, including those to quantify and report GHG emission reductions generated by eligible project activities. The requirements contained in this protocol are part of the Regulations and must be read in conjunction with provisions in the Regulations.

This protocol is designed to ensure a project generates GHG emission reductions that are real, additional, quantified, verified, unique and permanent. The protocol is also developed in accordance with the principles of ISO 14064-2:2019 Greenhouse gases – Part 2 – Specification with guidance at the project level for quantification, monitoring and reporting greenhouse gas emission reductions or removal enhancements to ensure reported GHG emission reductions generated as a result of implementing a project are relevant, complete, consistent, accurate, transparent, and conservative.

A project that uses biogas produced by an anaerobic digestion system instead of fossil fuels to produce energy may also generate GHG emission reductions from fossil fuel displacement (that is, fuel switching). However, when the GHG emission reductions are from sources that are subject to a federal or provincial pricing mechanism for GHG emissions, GHG emission reductions from fossil fuel displacement are not additional and are not eligible for federal offset credit issuance.

The proponent is also responsible for ensuring that any GHG emission reductions credited under Canada’s GHG Offset Credit System are unique, that is, they are not credited under another offset program or another GHG reduction mechanism.

2.0 Terms and definitions

Act
means the Greenhouse Gas Pollution Pricing Act.
Adjacent destruction facility
means a facility adjacent to the manure treatment site where biogas produced by a project anaerobic digestion (AD) manure treatment system (MTS) is combusted and methane (CH4) is destroyed in an eligible destruction device.
Anaerobic digestion manure treatment system (AD MTS)
means an MTS engineered to maximize anaerobic CH4 production (for example, through controlled heating, mixing and/or the addition of enzymes) and capture CH4 for energy generation, including all equipment operated for the treatment of eligible manure and associated outputs such as a digester, treated manure storage, biogas purification systems, and eligible destruction devices.
Anaerobic storage
means the storage of liquid manure under anaerobic conditions for more than 24h in a storage structure with a depth equal to or more than 1 m, such as an earthen basin or lagoon, a tank, a deep pit, or under-barn storage structure.
Biogas
means a gaseous mixture consisting primarily of CH4 and biogenic carbon dioxide (CO2), that is produced by the anaerobic decomposition of organic matter (for example, in liquid manure) in an anaerobic storage structure or by treatment of organic matter in an AD MTS.
Biogas can be used directly as a fuel, for example, to generate heat or electricity, or may be upgraded to meet the standards for injection into a natural gas network as renewable natural gas (RNG).
Biogenic CO2
means CO2 resulting from the decomposition of manure and the destruction of manure CH4.
Biogenic CO2 is considered to be part of the natural carbon cycle.
Chemical manure treatment system (chemical MTS)
means an MTS in which a chemical agent, such as a strong acid, is added to the manure, including all equipment operated for the treatment of eligible manure and associated outputs such as acidification tanks and treated manure storage.
Eligible destruction device
means a device, listed in Table 1, that combusts biogas produced by a project AD MTS, destroys manure CH4 and converts it into biogenic CO2 to generate greenhouse gas (GHG) emission reductions.
Feedstock
means any organic material treated by a project MTS, such as eligible manure, non-eligible manure, crop residues, and food industry organic waste.
Global warming potential (GWP)
means a metric representing the ability of a GHG to trap heat in the atmosphere compared to CO2, as set out in Schedule 3 to the Act.
Livestock operation
means the facility, including the land and buildings, used for the raising of livestock and the storage of livestock liquid and solid manure.
Liquid manure
means livestock excreta containing less than 20% of dry matter content by mass, which may include added water and/or organic or inorganic bedding material such as straw or sand.
Liquid treated manure
means eligible manure treated by a project MTS and containing less than 20% of dry matter content by mass, which may include the acidified manure from a chemical MTS, the liquid output of a mechanical MTS, or the liquid output of an AD MTS.
The liquid output of an AD MTS, also known as digestate, may be composed of treated manure plus other treated feedstock when the project MTS treats other feedstock in addition to eligible manure.
Manure methane (manure CH4)
means the CH4 portion of biogas produced by the anaerobic decomposition of liquid manure stored in an anaerobic storage structure or by the treatment of manure in an AD MTS.
Manure treatment site
means the area where a project MTS and all supporting buildings and infrastructure are located.
Eligible manure or treated manure storage structures and eligible destruction devices may be located outside of the manure treatment site, such as at the site of other livestock operations or at an adjacent destruction facility.
Manure treatment system (MTS)
means a system preventing the emission of eligible manure CH4 to the atmosphere, by reducing manure CH4 production during storage and by converting manure CH4 into biogenic CO2 in the case of an AD MTS.
Mechanical manure treatment system (mechanical MTS)
means an MTS separating the liquid and solid phases of eligible manure by mechanical means such as a filter, press, centrifuge, or other mechanical separation method, including all equipment operated for the treatment of eligible manure and associated outputs and liquid or solid treated manure storage.
Project site
means the area, contiguous or non-contiguous, where all storage sites, the manure treatment site, supporting buildings and infrastructure related to CH4 destruction, and any adjacent destruction facilities are located as part of a project.
Project MTS
means all AD MTS, chemical MTS or mechanical MTS installed and operated in a project.
Regulations
means the Canadian Greenhouse Gas Offset Credit System Regulations.
Solid manure
means livestock excreta which contains at least 20% of dry matter content by mass due to the loss of moisture by evaporation or the presence of organic or inorganic bedding material.
Solid treated manure
means eligible manure treated by a project MTS and containing at least 20% of dry matter content by mass, which may include the coarse solid and fine solid phases from a mechanical MTS.
Storage site
means the area where a storage structure is used to store eligible manure in the baseline scenario, or solid or liquid treated manure from a project MTS for a period of more than 24 hours.
The storage site may be adjacent or not to the manure treatment site.
Treated manure
means both liquid treated manure and solid treated manure.
Under-barn storage
means the storage of liquid manure in a structure located below a slatted floor in an enclosed animal confinement facility; often used for swine.

Under-barn storage is considered as anaerobic storage if depth is equal to or more than 1 m.

3.0 Baseline scenario

3.1 Baseline conditions

For a project to be eligible under this protocol, at least one of the following baseline conditions must be met at the project site:

In addition, for any livestock operation, the following baseline conditions must be met for at least 10 years before the project start date or, if the livestock operation was established less than 10 years before the project start date, since its establishment:

3.2 Determining the baseline scenario

The baseline scenario for a project implemented following this protocol is the release of manure CH4 to the atmosphere from anaerobic storage of eligible manure. GHG emissions from the anaerobic storage of eligible manure that would have occurred in the absence of the project (baseline scenario) are quantified using a dynamic baseline approach, as per Section 8.1.1.

In addition, where an AD MTS is part of a project and produces biogas eligible for fossil fuel displacement, as per Section 4.4, and the proponent chooses to quantify the resulting GHG emission reductions for federal offset credit issuance, the proponent must determine the type and the annual amount of fossil fuels that would have been used in the baseline scenario. The proponent must quantify these baseline scenario GHG emissions as per Section 8.1.2.

4.0 Project scenario

4.1 Project conditions

To be eligible under this protocol, a project must meet the following project conditions:

A project MTS may treat any feedstock, but only eligible manure can generate GHG emission reductions from anaerobic storage under this protocol.

Structures storing eligible manure may have been installed and operated prior to January 1, 2017.

4.2 Eligible manure

Manure that is to be treated in a project must meet the following conditions to be considered as eligible manure under this protocol:

4.3 Eligible project activities

Eligible project activities are the treatment of eligible manure using one or more of the following MTS types that are installed and operated within the project site:

Table 1: Eligible destruction devices
Type Description
Open flare A device with a pilot flame at the top of a vertical stack that is exposed to atmosphere that combusts a gas.
Enclosed flare A device with an insulated cylinder stack surrounding a burner manifold and combustion/cooling air louvers that combusts a gas.
Boiler A device that combusts a fuel in order to heat a fluid, such as water or leachate, generating vapour that provides thermal energy for various purposes.
Turbine (micro or large) A device that compresses air to combust with a fuel in order to produce expanding gas that turns turbine blades, generating mechanical energy that can be harnessed by a load (for example, a generator producing electricity).
Internal combustion engine (stationary or mobile) A device that compresses and combusts an air-fuel mixture in a cylinder in order to produce expanding gas that moves a piston and crankshaft, generating rotary mechanical energy that can be harnessed by a load (for example, a generator producing electricity).
Station for direct injection of upgraded biogas into a natural gas networkFootnote 1 A device that monitors and prepares upgraded biogas for injection into a natural gas network; this can include odourizing the gas, metering the flow, regulating the pressure, and monitoring the chemical composition prior to injection.
Station for compression or liquefaction of upgraded biogas prior to transport and injection into a natural gas network A device that compresses or liquefies upgraded biogas for transport to a station for its injection into a natural gas network (see above).

If the proponent is not the owner of the project MTS, or any part of the project MTS, the proponent must have an agreement with the owner to ensure:

4.4 Eligible biogas for displacement of fossil fuels

The biogas produced by a project AD MTS and destroyed in an eligible destruction device generating energy may displace fossil fuels.

If a project AD MTS treats other feedstocks in addition to eligible manure, biogas produced by all feedstocks can generate GHG emission reductions from the displacement of fossil fuels under this protocol, if the conditions are met. However, only eligible manure can generate GHG emission reductions from anaerobic storage.

The biogas produced by the project AD MTS and used to displace fossil fuels is eligible to generate GHG emission reductions under this protocol, provided the following conditions are met:

5.0 Additionality

5.1 Legal additionality

GHG emission reductions generated by a project must not occur as a result of federal, provincial, or territorial law (including regulations), municipal by-laws, or any other legally binding mandates. This includes legal requirements to control the release of manure biogas or to treat all or a portion of manure to reduce GHG emissions from the livestock operation or for odour or pollutant control (for example, requirements to use biofilters or chemical treatments).

If at any time after project registration the GHG emission reductions generated by the project become required by law or the result of a legal requirement, the GHG emission reductions will no longer be additional and, therefore, federal offset credits can only be issued for GHG emission reductions generated up to the date immediately preceding the date on which the law or the legal requirement comes into force.

5.2 Provincial or federal pricing mechanisms for GHG emissions

GHG emission reductions from sources that are subject to a federal or provincial pricing mechanism for GHG emissions are not eligible for federal offset credits.

6.0 General requirements

6.1 Project start date

The start date of a project corresponds to the first day eligible manure enters the project MTS to be treated.

6.2 Project site location and geographic boundaries

The proponent must document the location and geographic boundaries of the project site and prepare a site plan. The site plan must show and clearly label:

The geographic boundary of the project site must be established as per the Regulations.

6.3 Environmental and social safeguards

6.3.1 Compliance with applicable environmental legal requirements

The proponent must ensure that the project activities and the project site comply with all applicable laws, including regulations, municipal by-laws, operating permits, and other applicable legal requirements, such as those related to minimizing odour, emergency venting, protecting air and water quality, and managing nutrients from manure.

The proponent must also ensure that any output of the project MTS is disposed of in accordance with all applicable legal requirements, including from relevant federal, provincial, or territorial regulations, and municipal by-laws. Disposal includes, but is not limited to, land application and discharge into water bodies.

6.3.2 Safeguards for land application of acidified liquid treated manure

Acidified liquid treated manure from a chemical MTS will have a lower pH and a higher nitrogen content than untreated manure. To prevent negative impactsFootnote 2 from land application of acidified liquid treated manure, the proponent must ensure that all lands receiving acidified liquid treated manure during a reporting period are covered by a crop nutrient management plan or similar fertilizer management document completed by a Professional Agrologist (P.Ag.) or Certified Crop Advisor (CCA). The plan or document must:

The proponent must ensure that recommendations in the crop nutrient plan or similar fertilizer management document for managing soil acidification risks and nitrogen content are implemented.

7.0 Project GHG boundary

The project GHG boundary (Figure 1) contains the SSRs that must be included or excluded by the proponent in the baseline and project scenarios to determine the GHG emission reductions generated by the project.

Table 2 provides additional details on the SSRs identified for the baseline and project scenarios, as well as justification for their inclusion or exclusion in the quantification of GHG emission reductions. The proponent must assess each of the “included” SSRs that are relevant to the baseline and project scenarios.

Three GHGs are relevant to the SSRs in this protocol: carbon dioxide (CO2), methane (CH4), and nitrous oxide (N2O). Biogenic CO2 is excluded from the quantification of GHG emission reductions under this protocol, that is, biogenic CO2 from SSR 9, SSR 12, SSR 13, SSR 14, SSR 16 and SSR 17.Footnote 3

Figure 1: Illustration of the project GHG boundary

See long description below
Long description

Figure 1 depicts an illustration of the project GHG boundary. This includes the 18 SSRs relevant to the project type, a dotted line delineating those within the project GHG boundary, and symbols depicting the relationship and connection between SSRs.

SSR 1, SSR 2 and SSR 10 are related to the baseline and project scenarios and are outside the project GHG boundary as the difference between the baseline and project scenarios is assumed to be negligible.

SSR 4 is related to the project scenario only and is outside the project GHG boundary as it is assumed to be negligible.

The remaining SSRs are within the project GHG boundary and are organized in four groupings corresponding to the operation of manure treatment systems, storage of manure, combustion of biogas, and transport of manure, chemicals and treated manure.

SSR 6, SSR 7, SSR 11, SSR 12 and SSR 13 are related to the project scenario only and correspond to the operation of manure treatment systems.

SSR 9 is related to the baseline and project scenarios and corresponds to the storage of manure.

SSR 14, SSR 15, SSR 16 and SSR 17 are related to the project scenario only and correspond to the combustion of biogas.

SSR18 is related to the baseline scenario only and corresponds to the combustion of fossil fuels displaced by biogas.

SSR 3, SSR 5 and SSR 8 correspond to the transport of manure, chemicals and treated manure and are related to project scenario only.

SSR 1 leads SSR 2 which leads to SSR 3 which leads to SSR 6, SSR 7, SSR 9 and SSR 11 individually. SSR 4 leads to SSR 5 which leads to SSR 6. SSR 7 and SSR 11 are interconnected and can lead to either SSR 6 or SSR 8 which both lead to SSR 9 which eventually leads to SSR 10. SSR 11 also leads to SSR 12, SSR 13, SSR 14, SSR 15 and SSR 16 individually. SSR 15 leads to SSR 14 exclusively. SSR 18 is connected exclusively to SSR 17.

Table 2: Details on baseline and project scenario SSRs
SSR Title Description Type Baseline or project scenario GHG Included or excluded
1 Enteric fermentation Enteric fermentation of the feed consumed by livestock. Related Baseline (B1) Project (P1) CH4 Excluded: The difference in GHG emissions between the baseline and project scenarios is assumed to be negligible.
2 Manure collection Combustion of fossil fuels or consumption of grid electricity for the operation of the eligible manure collection system. Related Baseline (B2) Project (P2) CO2 Excluded: The difference in GHG emissions between the baseline and project scenarios is assumed to be negligible.
CH4
N2O
3 Manure transport Combustion of fossil fuels in vehicles used to transport eligible manure to the storage or treatment site. Controlled Project (P3) CO2 Included: Quantified based on fossil fuels usage, using Equation 7.
CH4
N2O
4 Chemical production Combustion of fossil fuels and process emissions for the production of chemicals used in a project chemical MTS. Affected Project (P4) CO2 Excluded: GHG emissions from this source are assumed to be negligible.
CH4
N2O
5 Chemical transport Combustion of fossil fuels in vehicles used to transport chemicals from the point of retail to the site of the project chemical MTS. Controlled Project (P5) CO2 Included: Quantified based on fossil fuels usage, using Equation 7.
CH4
N2O
6 Chemical treatment Combustion of fossil fuels or consumption of grid electricity for the operation of the project chemical MTS. Fossil fuels: Controlled Electricity: Related Project (P6) CO2 Included: Quantified based on energy usage, using Equation 7 and/or Equation 8.
CH4
N2O
7 Mechanical treatment Combustion of fossil fuels or consumption of grid electricity for the operation of the project mechanical MTS. Fossil fuels: Controlled Electricity: Related Project (P7) CO2 Included: Quantified based on energy usage, using Equation 7 and/or Equation 8.
CH4
N2O
8 Treated manure transport Combustion of fossil fuels in vehicles used to transport treated manure to the storage site or direct land application. Controlled Project (P8) CO2 Included: Quantified based on fossil fuels usage, using Equation 7.
CH4
N2O
9 Manure storage Eligible manure or treated manure decomposition during storage. Controlled Baseline (B9) Project (P9) CH4 Included: Quantified for eligible manure using Equation 2 or Equation 3, and for treated manure, as per Section 8.2.3.
N2O Included: For solid treated manure using Equation 21 or Equation 22.
Excluded: For liquid treated manure, GHG emissions from this source are not expected to increase in the project scenario compared to the baseline scenario.
10 Land application Combustion of fossil fuels in equipment used to apply eligible manure or treated manure to the land and emissions from eligible manure or treated manure decomposition in the soil. Related Baseline (B10) Project (P10) CO2 Excluded: GHG emissions from this source are not expected to increase in the project scenario with a mechanical or AD MTS compared to the baseline scenario. Any risk of increased N2O emissions from land application of acidified treated manure is addressed through safeguards prescribed in Section 6.3.2.
CH4
N2O
11 Anaerobic digestion Combustion of fossil fuels or consumption of grid electricity for the operation of the project AD MTS. Fossil Fuels: Controlled Electricity: Related Project (P11) CO2 Included: Quantified based on energy usage, using Equation 7 and/or Equation 8.
CH4
N2O
12 Leaks Release of biogas due to continuous leaks in the AD MTS. Controlled Project (P12) CH4 Included: Quantified based on a default or site-specific rate, using Equation 10
N2O Excluded: N2O emissions from biogas leaks are assumed to be negligible.
13 Emergency venting Release of biogas due to emergency venting. Controlled Project (P13) CH4 Included: Quantified based on a default or site-specific rate, using Equation 13.
N2O Excluded: N2O emissions from this source are assumed to be negligible.
14 Biogas combustion – Flare Combustion of biogas in an open or enclosed flare, as set out in Table 1. Controlled Project (P14) CH4 Included: Quantified based on the incomplete destruction of CH4 and the generation of N2O from the combustion of biogas in a flare, using Equation 14.
N2O
15 Supplemental fossil fuel combustion – Flare Combustion of supplemental fossil fuels to support the operation of an open or enclosed flare. Controlled Project (P15) CO2 Included: Quantified based on combustion of supplemental fossil fuels in a flare, using Equation 17.
CH4
N2O
16 Biogas combustion – Injection in natural gas network Combustion of upgraded biogas after its injection into a natural gas network with or without compression or liquefaction, as set out in Table 1. Controlled Project (P16) CH4 Included: Quantified based on the incomplete destruction of CH4 and the N2O emissions generated from the combustion of biogas in an eligible destruction device, using Equation 14.
N2O
17 Biogas combustion – Boiler, turbine or engine Combustion of biogas in a boiler, turbine or internal combustion engine, as set out in Table 1. Controlled Project (P17) CH4 Included: Quantified based on the incomplete destruction of CH4 and the N2O emissions generated from the combustion of biogas in an eligible destruction device, using Equation 14.
N2O
18 Combustion of fossil fuels displaced by biogas GHG emissions from the combustion of fossil fuels in the baseline scenario that are displaced by eligible biogas produced in the project scenario Controlled Baseline (B18) CO2 Included: Quantified for fossil fuels displaced by eligible biogas, as per Section 4.4, based on the volume of fossil fuels that would have been needed to produce the amount of energy generated by CH4 from the eligible biogas produced by the project AD MTS using Equation 4.
CH4
N2O

8.0 Quantification methodology

This section contains the quantification methodology that the proponent must follow to quantify baseline and project scenario GHG emissions and subsequently, the GHG emission reductions generated by the project.

Baseline scenario GHG emissions are the GHG emissions from the SSRs within the project GHG boundary that would likely have occurred in the absence of the project from the business-as-usual management of the same amount of eligible manure treated in the project scenario. Baseline scenario GHG emissions are quantified based on GHG emissions from the anaerobic storage of eligible manure, and, if applicable, GHG emissions that would have occurred in the absence of the project from the combustion of fossil fuels displaced by eligible biogas, as per Section 8.1.

Project scenario GHG emissions are the GHG emissions from the SSRs within the project GHG boundary that are generated from the eligible project activities, and quantified as per Section 8.2.

The GHG emission reductions generated by the project are quantified by deducting the project scenario GHG emissions from the baseline scenario GHG emissions, as per Section 8.4.

The quantification of both the baseline and project scenario GHG emissions must include all the GHG emissions that were likely to occur in the absence of the project (baseline scenario) and did occur (project scenario) during a reporting period. The proponent must report the sub-totals in tonnes of CO2 equivalent (t CO2e) for each full or partial calendar year of the reporting period to support issuance of the offset credits by calendar year.

For an aggregation of projects, the proponent must quantify GHG emission reductions for each project separately. Subsequently, the GHG emission reductions for each project are to be summed together to determine the GHG emission reductions for the aggregation of projects. The proponent must report the sub-totals of each project within the aggregation in tonnes of CO2 equivalent (t CO2e) for each full or partial calendar year of the reporting period to support issuance of the offset credits by calendar year.

Some emission factors and other reference values used in the quantification methodology are provided in the Emission Factors and Reference Values document.Footnote 4 Raw data must be converted to align with the units presented in the quantification methodology, if necessary.

8.1 Baseline scenario GHG emissions

The proponent must use Equation 1 and the subsequent equations in Section 8.1 to quantify the baseline scenario GHG emissions for each full or partial calendar year covered by the reporting period, based on the included SSRs as set out in Table 2.

The baseline scenario GHG emissions are quantified using a dynamic baseline approach based on eligible manure that is treated in the project scenario.

Equation 1: Baseline scenario GHG emissions for a calendar year covered by the reporting period

BE C = ( i n BSE i , C ) + FDE C

Parameter Description Units
BEC Baseline scenario GHG emissions for a calendar year covered by the reporting period t CO2e
BSEi,C Baseline scenario CH4 emissions from the anaerobic storage of eligible manure from livestock operation, i, for a calendar year covered by the reporting period, as per Equation 2 or Equation 3 (SSR B9) t CO2e
FDEC Baseline scenario GHG emissions from the combustion of fossil fuels displaced by eligible biogas for a calendar year covered by the reporting period, as per Equation 4 (SSR B18) t CO2e
i Livestock operation unitless
n Number of livestock operations from which eligible manure is sourced during a calendar year covered by the reporting period. If BSE is quantified as per Equation 3, n = 1 unitless
C Calendar year unitless

8.1.1 Baseline scenario CH4 emissions from the anaerobic storage of eligible manure

To quantify baseline scenario CH4 emissions from the anaerobic storage of eligible manure, the proponent must use the equation of one of the following two options:

In all cases, the proponent must derive a site-specific methane conversion factor (MCF), determined as per Section 9.1.5.

Equation 2: Baseline scenario CH4 emissions from anaerobic storage of eligible manure based on VS content for a calendar year covered by the reporting period

BSE i , C = m M ( QM i , m × VS source , i , m ) × B 0 , l × MCF C × ρ CH 4 1000 × GWP CH 4

Parameter Description Units
BSEi,C Baseline scenario CH4 emissions from the anaerobic storage of eligible manure from livestock operation, i, for a calendar year covered by the reporting period (SSR B9) t CO2e
QMi,m Quantity of eligible manure from livestock operation, i, treated by the project MTS in the project scenario for month, m, as per Sections 9.1.1 and 9.3 t
VSsource,i,m VS content of eligible manure from livestock operation, i, treated by the project MTS in the project scenario for month, m, before mixing with any other organic material, as per Sections 9.1.2 and 9.3 kg VS/t manure
B0,l Maximum CH4 producing potential for manure from livestock type, l, as set out in the Emission Factors and Reference Values document. If the livestock operation, i, includes more than one livestock type, B0 must correspond to the livestock type producing the largest quantity of eligible manure. m3 CH4/kg VS
MCFC Site-specific methane conversion factor for a calendar year covered by the reporting period, as per Section 9.1.5 unitless
ρCH4 Reference density of CH4 = 0.656 kg CH4/m3 CH4
1000 Conversion factor, kilograms to tonnes kg/t
GWPCH4 GWP of CH4, as set out in Schedule 3 to the Act unitless
M Number of months during a calendar year covered by the reporting period unitless
m Month unitless
i Livestock operation unitless
l Livestock type, as set out in the Emission Factors and Reference Values document unitless
C Calendar year unitless

Equation 3: Baseline scenario CH4 emissions from anaerobic storage of eligible manure based on the number of livestock for a calendar year covered by the reporting period

BSE i , C = l L ( LHC l , C × VS rate , l × B 0 , l × D l , C ) × MCF C × ρ CH 4 1000 × GWP CH 4

Parameter Description Units
BSEi,C Baseline scenario CH4 emissions from the anaerobic storage of eligible manure from livestock operation, i, for a calendar year covered by the reporting period (SSR B9) t CO2e
LHCl,C Average number of livestock from livestock type, l, producing eligible manure treated by the project MTS, for a calendar year covered by the reporting period, as per Sections 9.1.3 and 9.3 head
VSrate,l VS excretion rate for a livestock type, l, producing eligible manure treated by the project MTS for a calendar year covered by the reporting period, as set out in the Emission Factors and Reference Values document kg VS/head/day
B0,l Maximum CH4 producing potential for manure from livestock type, l, as set out in the Emission Factors and Reference Values document m3 CH4/kg VS
Dl,C Number of days of eligible manure production for livestock type, l, during a calendar year covered by the reporting period, as per Sections 9.1.3 and 9.3 day
MCFC Site-specific methane conversion factor for a calendar year covered by the reporting period, as per Section 9.1.5 unitless
ρCH4 Reference density of CH4 = 0.656 kg CH4/m3 CH4
1000 Conversion factor, kilograms to tonnes kg/t
GWPCH4 GWP of CH4, as set out in Schedule 3 to the Act unitless
L Number of livestock types from which eligible manure is sourced for a calendar year covered by the reporting period unitless
l Livestock type as set out in the Emission Factors and Reference Values document unitless
i Livestock operation unitless
C Calendar year unitless

8.1.2 Baseline scenario GHG emissions from the combustion of fossil fuels displaced by eligible biogas

If the project includes an AD MTS that produces eligible biogas for displacement of fossil fuels and the proponent chooses to quantify the resulting GHG emission reductions for credit issuance, they must use Equation 4 to quantify baseline scenario GHG emissions from the combustion of fossil fuels displaced by eligible biogas.

Equation 4: Baseline scenario GHG emissions from combustion of fossil fuels displaced by eligible biogas for a calendar year covered by the reporting period

FDE C = i n [ ( FD i , C × EF CO 2 , i ) + ( FD i , C × EF CH 4 , i × GWP CH 4 ) + ( FD i , C × EF N 2 O , i × GWP N 2 O ) ] ÷ 1000

Parameter Description Units
FDEC Baseline scenario GHG emissions from the combustion of fossil fuels displaced by eligible biogas for a calendar year covered by the reporting period (SSR B18) t CO2e
FDi,C Volume of fossil fuel, i, displaced by eligible biogas and used in the baseline scenario for a calendar year covered by the reporting period, as per Equation 5 m3
EFCO2,i CO2 emission factor for fossil fuel, i, as set out in the Emission Factors and Reference Values document kg CO2/m3
EFCH4,i CH4 emission factor for fossil fuel, i, as set out in the Emission Factors and Reference Values document kg CH4/m3
GWPCH4 GWP of CH4, as set out in Schedule 3 to the Act unitless
EFN2O,i N2O emission factor for fossil fuel, i, as set out in the Emission Factors and Reference Values document kg N2O/m3
GWPN2O GWP of N2O, as set out in Schedule 3 to the Act unitless
1000 Conversion factor, kilograms to tonnes kg/t
n Number of fossil fuels displaced by eligible biogas unitless
i Fossil fuel displaced by eligible biogas unitless
C Calendar year unitless

The volume of fossil fuels that would have been used in the baseline scenario to generate the equivalent amount of energy as the combustion of eligible biogas must be calculated using Equation 5. However, if the value of FDi,C , obtained from Equation 5, is higher than the highest annual volume of fossil fuels used during the 3 years before the project start date, the proponent must use this highest annual volume as the value of FDi,C in Equation 4.

Equation 5: Volume of fossil fuel displaced by eligible biogas for a calendar year covered by a reporting period

FD i , C = BGD C × ( HHV BG HHV FF , i )

Parameter Description Units
FDi,C Volume of fossil fuel, i, displaced by eligible biogas and used in the baseline scenario for a calendar year covered by the reporting period m3
BGDC Volume of biogas eligible for displacement of fossil fuels in the project scenario for a calendar year covered by the reporting period, as per Sections 9.1.6 and 9.3 m3
HHVBG Higher heating value of biogas produced by the project AD MTS, as set out in the Emission Factors and Reference Values document MJ/m3
HHVFF,i Higher heating value of fossil fuel, i, displaced by eligible biogas, as set out in the Emission Factors and Reference Values document MJ/m3
i Fossil fuel displaced by eligible biogas unitless
C Calendar year unitless

If eligible biogas has been upgraded to the standards required to be RNG, the proponent must use the applicable higher heating value for RNG, as set out in the Emission Factors and Reference Values document, for the parameter HHVBG in Equation 5.

If eligible biogas has not been upgraded to the standards required to be RNG, the proponent must use the higher heating value for biogas regardless of the CH4 composition of the biogas, as set out in the Emission Factors and Reference Values document, for the parameter HHVBG in Equation 5.

Despite the previous provision, the proponent may determine a project-specific higher heating value for eligible biogas by measuring the energy density of the biogas following the requirements for fuel heat content monitoring set out in Section 2.D.3 of the latest available version of Canada’s Greenhouse Gas Quantification Requirements / Greenhouse Gas Reporting Program, and corrected to standard conditions.

8.2 Project scenario GHG emissions

The proponent must use Equation 6 and the subsequent equations in Section 8.2 to quantify the project scenario GHG emissions for each full or partial calendar year covered by the reporting period, based on the included SSRs, as set out in Table 2.

The project scenario GHG emissions correspond to the GHG emissions from, as applicable:

Equation 6: Project scenario GHG emissions for a calendar year covered by the reporting period

PE C = FF C + EL C + ADE C + LTM C + STM C

Parameter Description Units
PEC Project scenario GHG emissions for a calendar year covered by the reporting period t CO2e
FFC GHG emissions from the combustion of fossil fuels for the transport of eligible manure (SSR P3), chemicals (SSR P5) and treated manure (SSR P8) and the operation of the project MTS (SSR P6, SSR P7 and SSR P11) for a calendar year covered by the reporting period, as per Equation 7 t CO2e
ELC GHG emissions from the use of grid electricity for the operation of the project MTS for a calendar year covered by the reporting period, as per Equation 8 (SSR P6, SSR P7 and SSR P11) t CO2e
ADEC GHG emissions specific to a project AD MTS from leaks (SSR P12), emergency venting (SSR P13), the incomplete destruction of CH4 and the generation of N2O from the combustion of biogas in eligible destruction device(s) (SSR P14, SSR P16 and P17), and the combustion of supplemental fossil fuels to support the operation of a flare (SSR P15) for a calendar year covered by the reporting period, as per Equation 9 t CO2e
LTMC CH4 emissions from the anaerobic storage of liquid treated manure in the project scenario for a calendar year covered by the reporting period, as per Equation 18 or Equation 20 (SSR P9) t CO2e
STMC GHG emissions from the storage of solid treated manure in the project scenario for a calendar year covered by the reporting period, as per Equation 21 or Equation 22 (SSR P9) t CO2e
C Calendar year unitless

8.2.1 Project scenario GHG emissions from fossil fuels combustion and energy usage

The proponent must use Equation 7 to quantify the GHG emissions from the combustion of fossil fuels used for the transport of eligible manure, chemicals, and treated manure as well as from the operation of the project MTS for a calendar year covered by the reporting period. For the GHG emissions from transport, the volume of fossil fuels consumed (FFi,C) is determined using the total transport distance and vehicle energy consumption data.

The proponent must use Equation 8 to quantify the GHG emissions from the use of grid electricity for the operation of the project MTS for a calendar year covered by the reporting period.

If both fossil fuels and grid electricity are used for the operation of the project MTS, the proponent must use the summation of Equation 7 and Equation 8 as the total GHG emissions for SSR P6, SSR P7 and SSRP11 for reporting purposes, as per Section 11.0.

Equation 7: GHG emissions from the combustion of fossil fuels for the transport of eligible manure, chemicals and treated manure and the operation of the project MTS for a calendar year covered by the reporting period

FF C = i n [ ( FF i , C × EF CO 2 , i ) + ( FF i , C × EF CH 4 , i × GWP CH 4 ) + ( FF i , C × EF N 2 O , i × GWP N 2 O ) ] ÷ 1000

Parameter Description Units
FFC GHG emissions from the combustion of fossil fuels for the transport of eligible manure (SSR P3), chemicals (SSR P5) and treated manure (SSR P8), and the operation of the project MTS (SSR P6, SSR P7 and SSR P11) for a calendar year covered by the reporting period t CO2e
FFi,C Volume of the type of fossil fuel, i, consumed by mobile and/or stationary equipment for the transport of eligible manure, chemicals, and treated manure and the operation of the project MTS, for a calendar year covered by the reporting period, as per Section 9.3 m3
EFCO2,i CO2 emission factor for fossil fuel, i, as set out in the Emission Factors and Reference Values document kg CO2/m3
EFCH4,i CH4 emission factor for fossil fuel, i, as set out in the Emission Factors and Reference Values document kg CH4/m3
GWPCH4 GWP of CH4, as set out in Schedule 3 to the Act unitless
EFN2O,i N2O emission factor for fossil fuel, i, as set out in the Emission Factors and Reference Values document kg N2O/m3
GWPN2O GWP of N2O, as set out in Schedule 3 to the Act unitless
1000 Conversion factor, kilograms to tonnes kg/t
n Number of fossil fuels displaced by eligible biogas unitless
i Fossil fuel displaced by eligible biogas unitless
C Calendar year unitless

Equation 8: GHG emissions from the use of grid electricity for the operation of the project MTS for a calendar year covered by the reporting period

EL C = GridEL × EF EL , GHG 1000

Parameter Description Units
ELC GHG emissions from the use of grid electricity for the operation of the project MTS for a calendar year covered by the reporting period (SSR P6, SSR P7 and SSR P11) t CO2e
GridEL Grid electricity consumed by the project MTS for a calendar year covered by the reporting period, as per Section 9.3 MWh
EFEL,GHG Emission factor for the electricity consumption GHG emission intensity for the grid of the project’s province or territory, as set out in the Emission Factors and Reference Values document kg CO2e/MWh
1000 Conversion factor, kilograms to tonnes kg/t

8.2.2 Project scenario GHG emissions specific to a project AD MTS

If the project includes an AD MTS, the proponent must use Equation 9 to quantify GHG emissions specific to the project AD MTS in the project scenario.

Equation 9: GHG emissions specific to a project AD MTS for a calendar year covered by the reporting period

ADE C = LK C + EV C + DBG C + FF Flare , C

Parameter Description Units
ADEC GHG emissions specific to a project AD MTS from leaks (SSR P12), emergency venting (SSR P13), the incomplete destruction of CH4 and the generation of N2O from the combustion of biogas in eligible destruction device(s) (SSR P14, SSR P16 and SSR P17), and the combustion of supplemental fossil fuels to support the operation of a flare (SSR P15) for a calendar year covered by the reporting period t CO2e
LKC GHG emissions from leaks from the project AD MTS for a calendar year covered by the reporting period, as per Equation 10 t CO2e
EVC GHG emissions from emergency venting of biogas from the project AD MTS for a calendar year covered by the reporting period, as per Equation 13 t CO2e
DBGC GHG emissions from the incomplete destruction of CH4 and the generation of N2O from the combustion of biogas in the eligible destruction device(s) for a calendar year covered by the reporting period, as per Equation 14 t CO2e
FFFlare,C GHG emissions from the combustion of supplemental fossil fuels to support the operation of a flare for a calendar year covered by the reporting period, as per Equation 17 t CO2e
C Calendar year unitless

The proponent must use Equation 10 to quantify GHG emissions from leaks from the project AD MTS.

Equation 10: GHG emissions from leaks from the project AD MTS for a calendar year covered by the reporting period

LK C = i n ( DM i , C ) × LR × ρ CH 4 1000 × GWP CH 4

Parameter Description Units
LKC GHG emissions from leaks from the project AD MTS for a calendar year covered by the reporting period (SSR P12) t CO2e
DMi,C Volume of CH4 delivered to an eligible destruction device, i, for a calendar year covered by the reporting period, as per Equation 11 m3 CH4
LR Leak rate for the project AD MTS = 0.05Footnote 5, or 0.005Footnote 6 if leak surveys are conducted as per Section 9.1.7 unitless
ρCH4 Reference density of CH4 = 0.656 kg CH4/m3 CH4
GWPCH4 GWP of CH4, as set out in Schedule 3 to the Act unitless
1000 Conversion factor, kilograms to tonnes kg/t
n Number of eligible destruction devices unitless
i Eligible destruction device unitless
C Calendar year unitless

Equation 11: CH4 delivered to eligible destruction devices for a calendar year covered by the reporting period

DM i , C = t n ( BG i , t × MC i , t )

Parameter Description Units
DMi,C Volume of CH4 delivered to an eligible destruction device, i, for a calendar year covered by the reporting period m3 CH4
BGi,t Corrected volume of biogas produced by the project AD MTS and delivered to an eligible destruction device, i, during measurement period, t, as per Section 9.3 if automatically corrected or as per Equation 12 if not automatically corrected m3 biogas
MCi,t Average CH4 content of the biogas delivered to the eligible destruction device, i, during measurement period, t, as per Section 9.3 m3 CH4/m3 biogas
n Number of measurement periods in a calendar year covered by the reporting period unitless
t Measurement period unitless
i Eligible destruction device unitless
C Calendar year unitless

All flow meter data must be corrected to the reference temperature and pressure conditions. If a flow meter does not automatically correct the measured volume to the reference temperature and pressure conditions, the proponent must quantify the corrected volume following Equation 12. Equation 12 is not needed if the flow meter automatically corrects the volume.

Equation 12: Volume of biogas produced by the project AD MTS delivered to an eligible destruction device, corrected to reference conditions

BG i , t = BG UC , i , t × T ref T i , t × P i , t P ref

Parameter Description Units
BGi,t Corrected volume of biogas produced by the project AD MTS and delivered to eligible destruction device, i, during measurement period, t m3 biogas
BGUC,i,t Uncorrected volume of biogas produced by the project AD MTS and delivered to eligible destruction device, i, during measurement period, t, as per Section 9.3 m3 biogas
Ti,t Measured temperature of the biogas produced by the project AD MTS and delivered to eligible destruction device, i, during the measurement period, t, as per Section 9.3 K
Tref Reference temperature of the biogas = 298.15 K K
Pi,t Measured pressure of the biogas produced by the project AD MTS and delivered to eligible destruction device, i, during the measurement period, t, as per Section 9.3 kPa
Pref Reference pressure of the biogas = 101.325 kPa kPa
t Measurement period unitless
i Eligible destruction device unitless

In the event of an emergency venting where biogas from the project AD MTS is released to the atmosphere, the proponent must use Equation 13 to quantify the corresponding CH4 emissions (SSR P13).

Equation 13: GHG emissions from emergency venting of biogas from the project AD MTS for a calendar year covered by the reporting period

EV C = ( BD + BG V 7 × TV ) × MC V 7 × ρ CH 4 1000 × GWP CH 4

Parameter Description Units
EVC GHG emissions from emergency venting of biogas from the project AD MTS for a calendar year covered by the reporting period (SSR P13) t CO2e
BD Estimated volume of stored biogas vented to the atmosphere, as per Section 9.1.8 m3 biogas
BGV7 Average flow of biogas produced by the project AD MTS during the 7 days preceding the emergency venting event, measured as the sum of BGi,t for all eligible destruction devices, as per Section 9.3 m3 biogas/h
TV Duration of emergency venting event h
MCV7 Average CH4 content of the biogas produced by the project AD MTS during the 7 days preceding the emergency venting event, measured as the average of MCi,t, for all eligible destruction devices, as per Section 9.3 m3 CH4/m3 biogas
ρCH4 Reference density of CH4 = 0.656 kg CH4/m3 CH4
GWPCH4 GWP of CH4, as set out in Schedule 3 to the Act unitless
1000 Conversion factor, kilograms to tonnes kg/t
C Calendar year unitless

The proponent must use Equation 14 to quantify GHG emissions from the incomplete destruction of CH4 and the generation of N2O from the combustion of biogas in eligible destruction devices (SSR P14 – flare, SSR P16 – injection in natural gas network and SSR P17 – boiler, turbine or engine), for each calendar year covered by the reporting period.

Equation 14: GHG emissions from the incomplete destruction of CH4 and the generation of N2O from the combustion of biogas in eligible destruction device(s) for a calendar year covered by the reporting period

DBG C = IDM C + CBG C

Parameter Description Units
DBGC GHG emissions from the incomplete destruction of CH4 and the generation of N2O from the combustion of biogas in the eligible destruction device(s) for a calendar year covered by the reporting period (SSR P14, SSR P16 and SSR P17) t CO2e
IDMC CH4 emissions from the incomplete destruction of CH4 in the eligible destruction device(s), for a calendar year covered by the reporting period, as per Equation 15 t CO2e
CBGC N2O emissions from the combustion of biogas in the eligible destruction device(s) for a calendar year covered by the reporting period, as per Equation 16 t CO2e
C Calendar year unitless

Equation 15: CH4 emissions from the incomplete destruction of CH4 in the eligible destruction device(s) for a calendar year covered by the reporting period

IDM C = i n [ DM i , C × ( 1 DE CH 4 , i ) ] × ρ CH 4 1000 × GWP CH 4

Parameter Description Units
IDMC CH4 emissions from the incomplete destruction of CH4 in the eligible destruction device(s), for a calendar year covered by the reporting period (SSR P14, SSR P16 and SSR P17) t CO2e
DMi,C Volume of CH4 delivered to an eligible destruction device, i, for a calendar year covered by the reporting period, as per Equation 11 m3 CH4
DECH4,i CH4 destruction efficiency of eligible destruction device, i, as set out in the Emission Factors and Reference Values document or specific to the device unitless
ρCH4 Reference density of CH4 = 0.656 kg CH4/m3 CH4
GWPCH4 GWP of CH4, as set out in Schedule 3 to the Act unitless
1000 Conversion factor, kilograms to tonnes kg/t
n Number of eligible destruction devices unitless
i Eligible destruction device unitless
C Calendar year unitless

The amount of CH4 destroyed in each eligible destruction device is dependent on the CH4 destruction efficiency for each device (DECH4). The Emission Factors and Reference Values document sets out default CH4 destruction efficiencies that the proponent must use for each eligible destruction device in the project.

Despite the previous provision, the proponent may determine a device-specific destruction efficiency for each eligible destruction device in the project. Testing for the device-specific destruction efficiency must be conducted each reporting period, and include at least 3 test runs, with the accepted final value being one standard deviation below the mean of the measured efficiencies.

Equation 16: N2O emissions from the combustion of biogas in the eligible destruction device(s) for a calendar year covered by the reporting period

CBG C = i n ( DM i , C ) × ρ CH 4 1000 × EF BG , N 2 O 1000 × GWP N 2 O

Parameter Description Units
CBGC N2O emissions from the combustion of biogas in the eligible destruction device(s) for a calendar year covered by the reporting period (SSR P14, SSR P16 and SSR P17) t CO2e
DMi,C Volume of CH4 delivered to an eligible destruction device, i, for a calendar year covered by the reporting period, as per Equation 11 m3 CH4
EFBG,N2O N2O emission factor for the combustion of biogas, as set out in the Emission Factors and Reference Values document kg N2O/t CH4
ρCH4 Reference density of CH4 = 0.656 kg CH4/m3 CH4
1000 Conversion factor, kilograms to tonnes kg/t
GWPN2O GWP of N2O, as set out in Schedule 3 to the Act unitless
n Number of eligible destruction devices unitless
i Eligible destruction device unitless
C Calendar year unitless

If a project AD MTS includes an open or enclosed flare, the proponent must use Equation 17 to quantify the GHG emissions from supplemental fossil fuels combusted to support the operation of the flare for each calendar year covered by the reporting period, which corresponds to SSR P15.

Equation 17: GHG emissions from the combustion of supplemental fossil fuels to support the operation of a flare for a calendar year covered by the reporting period

FF Flare , C = i n [ ( FF supp , i , C × EF CO 2 , i ) + ( FF supp , i , C × FF CH 4 , i × ρ CH 4 × ( 1 DE CH 4 ) × GWP CH 4 ) + ( FF supp , i , C × EF N 2 O , i × GWP N 2 O ) ] ÷ 1000

Parameter Description Units
FFFlare,C GHG emissions from the combustion of supplemental fossil fuels to support the operation of a flare for a calendar year covered by the reporting period (SSR P15) t CO2e
FFsupp,i,C Volume of supplemental fossil fuel, i, consumed by a flare for a calendar year covered by the reporting period, as per Section 9.3 m3
EFCO2,i CO2 emission factor for supplemental fossil fuel, i, as set out in the Emission Factors and Reference Values document kg CO2/m3
FFCH4,i Average CH4 content of supplemental fossil fuel, i, obtained from the supplier m3 CH4/m3
ρCH4 Reference density of CH4= 0.656 kg CH4/m3 CH4
DECH4 CH4 destruction efficiency of the flare, as set out in the Emission Factors and Reference Values document or specific to the device unitless
GWPCH4 GWP of CH4, as set out in Schedule 3 to the Act unitless
EFN2O,i N2O emission factor for supplemental fossil fuel, i, as set out in the Emission Factors and Reference Values document kg N2O/m3
GWPN2O GWP of N2O, as set out in Schedule 3 to the Act unitless
1000 Conversion factor, kilograms to tonnes kg/t
n Number of supplemental fossil fuels unitless
i Supplemental fossil fuel          unitless
C Calendar year unitless

8.2.3 Project scenario GHG emissions from the storage of treated manure

The proponent must quantify project scenario GHG emissions from the storage of liquid and solid treated manure streams, based on the storage type, as set out in the Emission Factors and Reference Values document. If the project includes more than one project MTS, the proponent must include all treated manure streams entering a storage type.

Treated manure that is temporarily stored for less than 24h may be excluded from the quantification.

8.2.3.1 CH4 emissions from the storage of liquid treated manure

The proponent must quantify CH4 emissions from the storage of liquid treated manure in the project scenario in accordance with the quantification method used for the baseline scenario CH4 emissions from the anaerobic storage of eligible manure, as follows:

Equation 18: CH4 emissions from the anaerobic storage of liquid treated manure based on VS content for a calendar year covered by the reporting period

LTM C = m M ( QLTM m × VS LTM , m ) × B 0 , Average × MCF C × CF MCF , s × ρ CH 4 1000 × GWP CH 4

Parameter Description Units
LTMC CH4 emissions from the anaerobic storage of liquid treated manure in the project scenario for a calendar year covered by the reporting period (SSR P9) t CO2e
QLTMm Quantity of liquid treated manure sent to anaerobic storage during the month, m, as per Sections 9.1.1 and 9.3 t
VSLTM,m VS measured from the liquid treated manure stored anaerobically, for the month, m, as per Sections 9.1.2 and 9.3 kg VS/t manure
B0,Average Weighted average of the maximum CH4 producing potential for treated manure, as per Equation 19, for projects treating manure from more than one livestock operation. For projects with one livestock operation, use the B0 value set out in the Emission Factors and Reference Values document corresponding to the main livestock type, l, raised at the livestock operation m3 CH4/kg VS
MCFC Site-specific methane conversion factor for a calendar year covered by the reporting period, as per Section 9.1.5 unitless
CFMCF,s MCF correction factor for liquid treated manure sent to a storage type, s, as set out in the Emission Factors and Reference Values document unitless
ρCH4 Reference density of CH4 = 0.656 kg CH4/m3 CH4
1000 Conversion factor, kilograms to tonnes kg/t
GWPCH4 GWP of CH4, as set out in Schedule 3 to the Act unitless
M Number of months during a calendar year covered by the reporting period unitless
m Month unitless
s Type of liquid treated manure storage unitless
C Calendar year unitless

Equation 19: Weighted average of the maximum CH4 producing potential for projects treating manure from more than one livestock operation

B 0 , Average = i n [ B 0 , i × QM i QM Total ]

Parameter Description Units
B0,Average Weighted average of the maximum CH4 producing potential for treated manure m3 CH4/kg VS
B0,i Maximum CH4 producing potential for treated manure for a livestock operation, i, as set out in the Emission Factors and Reference Values document. If the livestock operation, i, includes more than one livestock type, B0 must correspond to the livestock type producing the largest quantity of eligible manure m3 CH4/kg VS
QMi Quantity of eligible manure from livestock operation, i, treated by the project MTS in the project scenario for a calendar year covered by the reporting period, as per Sections 9.1.1 and 9.3 t
QMTotal Total quantity of eligible manure treated by the project MTS in the project scenario for a calendar year covered by the reporting period, as per Sections 9.1.1 and 9.3 t
n Number of livestock operations from which eligible manure is sourced during a calendar year covered by the reporting period. unitless
i Livestock operation unitless

Equation 20: CH4 emissions from the anaerobic storage of liquid treated manure based on number of livestock for a calendar year covered by the reporting period

LTM C = l L ( LHC l , C × VS rate , l × B 0 , l × D l , C ) × ( 1 Eff MTS ) × MCF C × ρ CH 4 1000 × GWP CH 4

Parameter Description Units
LTMC CH4 emissions from the anaerobic storage of liquid treated manure in the project scenario for a calendar year covered by the reporting period (SSR P9) t CO2e
LHCl,C Average number of livestock from livestock type, l, producing eligible manure treated by the project MTS, for a calendar year covered by the reporting period, as per Sections 9.1.3 and 9.3  head
VSrate,l VS excretion rate for a livestock type, l, producing eligible manure treated by the project MTS for a calendar year covered by the reporting period, as set out in the Emission Factors and Reference Values document kg VS/head/day
B0,l Maximum CH4 producing potential for manure from livestock type, l, as set out in the Emission Factors and Reference Values document m3 CH4/kg VS
Dl,C Number of days of eligible manure production for livestock type, l, during a calendar year covered by the reporting period, as per Sections 9.1.3 and 9.3 day
EffMTS Project-specific MTS efficiency rate as per Section 9.1.4 or, for a chemical MTS, instead use the value of CFMCF from liquid anaerobic storage, acidified, as set out in the Emission Factors and Reference Values document unitless
MCFC Site-specific methane conversion factor for a calendar year covered by the reporting period, as per Section 9.1.5 unitless
ρCH4 Reference density of CH4 = 0.656 kg CH4/m3 CH4
1000 Conversion factor, kilograms to tonnes kg/t
GWPCH4 GWP of CH4, as set out in Schedule 3 to the Act unitless
L Number of livestock types from which eligible manure is sourced for a calendar year covered by the reporting period unitless
l Livestock type as set out in the Emission Factors and Reference Values document unitless
C Calendar year unitless
8.2.3.2 GHG emissions from the storage of solid treated manure

The proponent must use Equation 21 to quantify the GHG emissions from the storage of solid treated manure in the project scenario based on default emission factors for all types of solid treated manure storage. Despite this provision, the proponent may use Equation 22 to quantify the GHG emissions from the storage of the solid treated manure based on its VS content, if the following conditions are met:

Equation 21: GHG emissions from the storage of solid treated manure based on default emission factors for a calendar year covered by the reporting period

STM C = s S [ ( QSTM s , C × EF TM , CH 4 , s 1000 × GWP CH 4 ) + ( QSTM s , C × EF TM , N 2 O , s 1000 × GWP N 2 O ) ]

Parameter Description Units
STMC GHG emissions from the storage of solid treated manure in the project scenario for a calendar year covered by the reporting period (SSR P9) t CO2e
QSTMs,C Quantity of solid treated manure sent to a storage type, s, for a calendar year covered by the reporting period, as per Section 9.3 t wet treated manure
EFTM,CH4,s Storage CH4 emission factor for solid treated manure sent to a storage type, s, as set out in the Emission Factors and Reference Values document kg CH4/t wet treated manure
EFTM,N2O,s Storage N2O emission factor for solid treated manure sent to a storage type, s, as set out in the Emission Factors and Reference Values document kg N2O/t wet treated manure
1000 Conversion factor, kilograms to tonnes kg/t
GWPCH4 GWP of CH4, as set out in Schedule 3 to the Act unitless
GWPN2O GWP of N2O, as set out in Schedule 3 to the Act unitless
S Number of solid treated manure storage types unitless
s Type of solid treated manure storage unitless
C Calendar year unitless

Equation 22: GHG emissions from the storage of solid treated manure based on VS content for a calendar year covered by the reporting period

STM C = s S ( STM CH 4 , s , C ) + [ m M ( QSTM s , m ) × EF TM , N 2 O , s 1000 × GWP N 2 O ]

Parameter Description Units
STMC GHG emissions from the storage of solid treated manure in the project scenario for a calendar year covered by the reporting period (SSR P9) t CO2e
STMCH4,s,C CH4 emissions from solid treated manure sent to a storage type, s, for a calendar year covered by the reporting period, as per Equation 23 t CO2e
QSTMs,m Quantity of solid treated manure sent to storage, s, during the month, m, as per Section 9.3 t wet treated manure
EFTM,N2O,s Storage N2O emission factor for solid treated manure sent to a storage type, s, as set out in the Emission Factors and Reference Values document kg N2O/t wet treated manure
GWPN2O GWP of N2O, as set out in Schedule 3 to the Act unitless
1000 Conversion factor, kilograms to tonnes kg/t
S Number of solid treated manure storage types unitless
s Type of solid treated manure storage unitless
M Number of months during a calendar year covered by the reporting period unitless
m Month unitless
C Calendar year unitless

Equation 23: CH4 emissions from the storage of solid treated manure based on VS content for a calendar year covered by the reporting period

STM CH 4 , s , C = m M ( QSTM m × VS STM , m ) × B 0 , Average × 0.02 × ρ CH 4 1000 × GWP CH 4

Parameter Description Units
STMCH4,s,C CH4 emissions from solid treated manure sent to a storage type, s, for a calendar year covered by the reporting period t CO2e
QSTMm Quantity of solid treated manure sent to storage for the month, m, as per Section 9.3 t wet treated manure
VSSTM,m VS of the solid treated manure from the project mechanical MTS for the month, m, as per Equation 24 kg VS/t manure
B0,Average Weighted average of the maximum CH4 producing potential for treated manure, as per Equation 19 m3 CH4/kg VS
0.02 Methane conversion factor for solid treated manure, adapted from the Intergovernmental Panel on Climate Change (IPCC)Footnote 7 unitless
ρCH4 Reference density of CH4 = 0.656 kg CH4/m3 CH4
1000 Conversion factor, kilograms to tonnes kg/t
GWPCH4 GWP of CH4, as set out in Schedule 3 to the Act unitless
M Number of months during a calendar year covered by the reporting period unitless
m Month unitless
s Type of solid treated manure storage unitless
C Calendar year unitless

Equation 24: VS of the solid treated manure from the project mechanical MTS

VS STM , m = VS LM , pre , m VS LTM , m

Parameter Description Units
VSSTM,m VS of the solid treated manure from the project mechanical MTS for the month, m kg VS/t manure
VSLM,pre,m VS measured from the eligible manure or liquid treated manure pre mechanical MTS for the month, m, as per Section 9.1.2 and 9.3 kg VS/t manure
VSLTM,m VS measured from the liquid treated manure stored anaerobically, that is, post mechanical MTS, for the month, m, as per Section 9.3 kg VS/t manure
m Month unitless

8.3 Leakage

A project in which the quantity of manure produced in the project scenario is reduced compared to the baseline scenario (for example, due to a reduction in livestock number) would pose a leakage risk if GHG emission reductions were quantified based on historical manure quantities. This form of leakage is avoided in this protocol by quantifying GHG emissions in the baseline scenario based on the quantity of manure that is treated in the project scenario (that is, using a dynamic baseline approach) to ensure functional equivalency between the baseline and project scenarios.

As a result, there is no leakage discount factor (which corresponds to variable Ci in the formula in subsection 20(2) of the Regulations) to be applied for the quantification of GHG emission reductions generated by a project implemented following this protocol.

8.4 Project GHG emission reductions

The proponent must use Equation 25 to quantify the GHG emission reductions (ERC) generated by the project, which correspond to the GHG reductions determined in accordance with section 20 of the Regulations.

Equation 25: Project GHG emission reductions for a calendar year covered by the reporting period

ER C = BE C PE C

Parameter Description Units
ERC Project GHG emission reductions for a calendar year covered by the reporting period t CO2e
BEC Baseline scenario GHG emissions for a calendar year covered by the reporting period, as per Equation 1 t CO2e
PEC Project scenario GHG emissions for a calendar year covered by the reporting period, as per Equation 6 t CO2e
C Calendar year unitless

9.0 Measurement and data

9.1   Data collection

If the proponent quantifies baseline scenario CH4 emissions from the anaerobic storage of eligible manure based on its VS content (Option 1 with Equation 2 as per Section 8.1.1), they must measure:

If the proponent quantifies baseline scenario CH4 emissions from the anaerobic storage of eligible manure based on the number of livestock (Option 2 with Equation 3 as per Section 8.1.1), they must determine:

Regardless of the option chosen to quantify baseline scenario CH4 emissions from the anaerobic storage of eligible manure, the proponent must:

9.1.1 Mass of eligible manure and treated manure

The proponent must measure the quantity of eligible manure and treated manure by volume or wet weight.

If eligible manure or treated manure is measured by volume, the volume must be converted to mass. A density of 1 tonne/m3 must be used for eligible manure and for liquid treated manure. The density of the solid treated manure from a mechanical MTS must be measured every 3 months and the average density must be used to convert volume to mass.

9.1.2 VS content

The proponent must determine the VS content monthly as follows:

In addition to the two VS content measures above, if the proponent uses Equation 22 to quantify project scenario GHG emissions from the storage of solid treated manure stored in static piles or composted, and if the project activity consists of an AD MTS followed by a mechanical MTS, the proponent must determine the VS content of the treated manure from the AD MTS and prior to entering the mechanical MTS and use it in Equation 24. The VS content of manure must be determined as follows:

9.1.3 Number of livestock and days of eligible manure production

The proponent must count the number of days eligible manure was produced and the number of livestock each day to support parameters LHCl,C and Dl,C.

For Dl,C the proponent must count the number of days in a calendar year that eligible manure treated by the project MTS was produced for each livestock type, l. Livestock types and their descriptions are set out in the Emission Factors and Reference Values document.

LHCl,C represents an average number of livestock for each livestock type, l, producing eligible manure treated by the project MTS. The proponent must, therefore, count the number of livestock for each livestock type, l, producing eligible manure treated by the project MTS each day eligible manure is produced by the livestock in a calendar year. The daily count must be averaged over the number of days eligible manure was produced by livestock type, l (Dl,C).

9.1.4 Project-specific MTS efficiency rate

The proponent must determine a project-specific MTS efficiency rate by determining the VS content of samples taken before and after treatment by the project MTS, as follows:

Equation 26: Efficiency rate for the project MTS

Eff MTS , i = ( VS before MTS , i VS after MTS , i ) VS before MTS , i

Parameter Description Units
EffMTS,i Project-specific MTS efficiency rate for sampling, i unitless
VSbeforeMTS,i VS in eligible manure before treatment by the project MTS, at sampling, i, as per Section 9.3 kg/t manure
VSafterMTS,i VS in liquid treated manure after treatment by the project MTS, at sampling, i, as per Section 9.3 kg/t manure
i Sampling (n ≥ 3) unitless

9.1.5 Methane conversion factor (MCF)

The proponent must determine a single site-specific MCF to be used in both the baseline and project scenarios. The site-specific MCF must be determined each calendar year covered by the reporting period following the method in Annex 10A.3 of the IPCC 2019 guidelinesFootnote 9 and the following requirements for determining input values:

A single MCF must be determined for the whole project site in the following situations:

In all other cases, the proponent must determine multiple MCF values as follows:

If the proponent must determine multiple MCF values, a single average site-specific MCF must be determined for each calendar year covered by the reporting period. For a single livestock operation with multiple under-barn storages, a simple average of the MCF for each under-barn storage structure must be used for the livestock operation. For a project site that includes multiple livestock operations, a weighted average must be used based on the quantity of manure treated as per Equation 27.

Equation 27: Site-specific MCF for a project site including multiple livestock operation for a calendar year covered by the reporting period to be used in both the baseline and project scenarios

MCF C = u n [ MCF u × QM u , C QM Total ]

Parameter Description Units
MCFC Site-specific MCF for a calendar year covered by the reporting period unitless
MCFu MCF determined for a specific removal frequency or under-barn storage, u. unitless
QMu,C Quantity of manure treated by the project MTS in the project scenario for a specific removal frequency or under-barn storage, u, for a calendar year covered by the reporting period t
QMTotal Total quantity of eligible manure treated by the project MTS in the project scenario for a calendar year covered by the reporting period t
n Number of different removal frequencies or under-barn storages requiring a unique MCF for a calendar year covered by the reporting period. unitless
u Removal frequency or under-barn storage requiring a unique MCF unitless
C Calendar year unitless

9.1.6 Volume of biogas eligible for displacement of fossil fuels

If the proponent quantifies GHG emissions from the combustion of fossil fuels displaced by eligible biogas using Equation 4, they must measure the volume of eligible biogas using measuring devices as per Section 9.2.4.2.

9.1.7 Leak surveys

To use a leak rate (LR) of 0.005 in Equation 10, the proponent must conduct leak surveys according to the following requirements:

When carrying out the leak surveys, a leak is defined as one of the following:

If the requirements above for using a leak rate of 0.005 are not met, the proponent must use a leak rate of 0.05 in Equation 10.

9.1.8 Emergency venting

The proponent must estimate the volume of biogas accumulated in the digester or in a secondary storage structure (that is, biogas bladder) that was vented to the atmosphere during an emergency venting event. If direct measurement is not possible, the volume of stored biogas may be determined by an engineering estimate.

9.2 Measuring devices

All measuring devices listed in this section must be operated according to the manufacturer's specifications.

9.2.1 General measuring devices

If the proponent quantifies baseline scenario CH4 emissions from the anaerobic storage of eligible manure based on the VS content (Option 1 with Equation 2 as per Section 8.1.1), they must use a measuring device to measure the quantity of eligible manure treated by the project MTS by weight or volume, such as with a flow meter, a truck scale or a volumetric sensor.

The quantity of grid electricity used for the operation of the project MTS must be measured by permanent meters or determined using purchase records.

For projects including one or more under-barn storage structure(s), temperature must be measured daily at mid-depth of the treated manure in the under-barn storage structure(s) and averaged to obtain a monthly average temperature.

9.2.2 Measuring devices specific to a project chemical MTS

If the project includes a project chemical MTS, the proponent must use a portable pH meter that directly measures pH in the treated manure storage at least daily.

9.2.3 Measuring devices specific to a project mechanical MTS

If the project includes a project mechanical MTS and if the proponent quantifies baseline scenario CH4 emissions from the anaerobic storage of eligible manure based on the VS content (Option 1 with Equation 2 as per Section 8.1.1), the proponent must use the following measuring devices:

9.2.4 Measuring devices specific to a project AD MTS

9.2.4.1 Treated manure measuring devices

If the project includes a project AD MTS and if the proponent quantifies baseline scenario CH4 emissions from the anaerobic storage of eligible manure based on the VS content (Option 1 with Equation 2 as per Section 8.1.1), the proponent must use a flow meter or a scale to measure treated manure by volume or weight at the frequency set out in Table 3.

9.2.4.2 Biogas flow meters

For any project AD MTS, the proponent must use a permanent flow meter that directly and separately measures the volume of biogas produced by the project MTS and delivered to each individual eligible destruction device at the frequency set out in Table 3.

9.2.4.3 Biogas temperature and pressure gauges

If the flow meter of a project AD MTS automatically corrects the biogas volume to the reference temperature and pressure conditions set out in Equation 12, no additional temperature and pressure gauges are required.

If the flow meter does not automatically correct the biogas volume, the proponent must use permanent temperature and pressure gauges to measure temperature and pressure at the same measurement frequency as the uncorrected volume of biogas (Section 9.3). Biogas temperature and pressure must be measured under the same conditions (wet or dry basis) as the biogas volume.

The biogas volume data must be corrected from measured temperature and pressure conditions to the reference temperature and pressure conditions using Equation 12.

9.2.4.4 Methane analyzers

For any project AD MTS, the proponent must use a permanent or portable methane analyzer (for example, gas chromatographs) that directly measures the CH4 content in the biogas on a volumetric basis at the frequency set out in Table 3.

9.2.4.5 Arrangement of biogas measuring devices

Flow meters and methane analyzers must be arranged in such a way as to ensure the data is representative of the biogas produced and combusted in the project.

For a project with multiple eligible destruction devices:

Additionally, flow meters and methane analyzers must be placed to:

Measuring devices must be arranged such that biogas CH4 content is measured under the same conditions (wet or dry basis) as biogas volume, temperature, and pressure. However, a moisture-removing component may separate a methane analyzer and a flow meter where the methane analyzer is placed upstream of the moisture-removing component (CH4 content measured on a wet basis), and the flow meter is placed downstream of the moisture-removing component (biogas volume measured on a dry basis). A moisture-removing component must not separate a methane analyzer and flow meter in any other configuration other than previously described. Other devices or equipment that could change the biogas composition by volume must not separate a methane analyzer and a flow meter.

9.2.4.6 Leak detection

To conduct leak surveys as per Section 9.1.7, the proponent must use a measuring device for leak detection that:

9.3 Measurement method and frequency

Table 3 identifies the parameters in the quantification methodology set out in Section 8.0 that must be measured and provides details regarding measurement method and frequency.

Table 3: Measurement method and frequency for measured parameters
Parameter Description Units Measurement method and frequency Equations
QMi Quantity of eligible manure from livestock operation, i, treated by the project MTS t

Measured continuously by volume or weight, recorded at least once every 15 minutes during the operational period of the MTS, and summed for each month in each calendar year covered by the reporting period.

or

If the eligible manure is transported by truck to the MTS site, measured by volume or weight for each truck load.

2, 19
VSsource VS content of eligible manure from livestock operation, i, that is treated by the project MTS before mixing with any other organic material kg VS / t manure Measured monthly at a minimum and upon change in eligible manure source as per Section 9.1.2. 2
Dl Number of days of eligible manure production for livestock type, l day Determined at the end of the calendar year as per Section 9.1.3 3, 20
LHCl Average number of livestock from livestock type, l, producing eligible manure treated by the project MTS head Counted each day eligible manure treated by the project MTS is produced day and averaged as per section 9.1.3.   3, 20
BGD Volume of biogas eligible for displacement of fossil fuels m3

Measured continuously, recorded at least every hour and summed for each calendar year covered by the reporting period.

or

Quantified as per Equation 12 if flow meter does not automatically correct volume.

5
FFi Volume of the type of fossil fuel, i, consumed by mobile and/or stationary equipment for the transport of eligible manure, chemicals, and treated manure, and for the operation of the project MTS m3 Calculated from fossil fuels purchase records and/or equipment specifications and summed for each calendar year covered by the reporting period. 7
GridEL Grid electricity consumed by the project MTS MWh

Measured using meter and summed for each calendar year covered by the reporting period.

or

Calculated from electricity purchase records and/or equipment specifications and summed for each calendar year covered by the reporting period.

8
BGi,t Corrected volume of biogas produced by the project AD MTS and delivered to eligible destruction device, i, during a measurement period, t m3 biogas

Measured continuously and recorded every measurement period. The measurement period can be a maximum of 1h.

or

Quantified as per Equation 12 if flow meter does not automatically correct volume.

11
MCi,t Average CH4 content of the biogas delivered to the eligible destruction device, i, during measurement period, t m3 CH4 /m3 biogas Measured continuously and averaged over the measurement period. The measurement period can be a maximum of 1h. 11
BGUC,i,t Uncorrected volume of biogas produced by the project AD MTS and delivered to eligible destruction device, i, during measurement period, t m3 biogas Measured continuously and recorded every measurement period. The measurement period can be a maximum of 1h. 12
Ti,t Measured temperature of the biogas produced by the project AD MTS and delivered to eligible destruction device, i, during the measurement period, t K Measured continuously and recorded every measurement period if flow meter does not automatically correct volume. The measurement period can be a maximum of 1h but must be the same frequency as for BGUC. 12
Pi,t Measured pressure of the biogas produced by the project AD MTS and delivered to eligible destruction device, i, during the measurement period, t kPa Measured continuously and recorded every measurement period if flow meter does not automatically correct volume. The measurement period can be a maximum of 1h but must be the same frequency as for BGUC. 12
FFsupp,i Volume of supplemental fossil fuel, i, consumed by a flare m3 Calculated from fossil fuels purchase records and/or equipment specifications and summed for each calendar year covered by the reporting period. 17
QLTM Quantity of liquid treated manure sent to anaerobic storage t

Measured continuously by volume or weight, recorded at least once every 15 minutes and summed for each calendar year covered by the reporting period.

or

If the treated manure is transported by truck to the storage site, measured by volume or weight for each truck load.

18
VSLTM VS measured from liquid treated manure stored anaerobically kg VS/t manure Measured monthly at a minimum and upon a change of 5% or more in eligible manure composition (based on livestock type l) or a change in source of other organics. 18, 24
QSTM Quantity of solid treated manure sent to storage t wet treated manure

Measured continuously by volume or weight, recorded at least once every 15 minutes and summed for each calendar year covered by the reporting period.

or

If the treated manure is transported by truck to the storage site, measured by volume or weight for each truck load.

21, 22, 23
VSLM,pre VS measured from the eligible manure or liquid treated manure pre mechanical MTS kg VS/t manure Measured monthly at a minimum and upon a change of 5% or more in eligible manure composition (based on livestock type, l) or a change in source of other organics. 24
VSbeforeMTS,i VS content of eligible manure of the sample, i, before treatment by the project MTS kg/t manure Measured a minimum of 3 evenly distributed times during each 12-month period within the reporting period as per Section 9.1.4 26
VSafterMTS,i VS content of liquid treated manure of the sample, i, after treatment by the project MTS kg/t manure Measured a minimum of 3 evenly distributed times during each 12-month period within the reporting period as per Section 9.1.4 26

9.4 Quality assurance and quality control

The proponent must have documented quality assurance and quality control (QA/QC) procedures and must implement them to ensure that all measurements and calculations are made in accordance with this protocol and can be verified.

All measuring devices listed in Section 9.2, except for grid electricity meters and leak detection measuring devices operated by a third party certified for that purpose, must be checked for accuracy by following manufacturer specifications at least once each calendar year, with the last occurring no more than 2 months before or after the end of the reporting period.

The measurement accuracy of all these measuring devices must be within a ± 5% accuracy range. When the measurement accuracy of a measuring device exceeds the ± 5% range, the appropriate corrective actions must be taken on the device, in accordance with the manufacturer specifications.

After the corrective actions, the measuring device must be rechecked for accuracy. If the measurement accuracy of the measuring device is still not within the ± 5% range, the measuring device must be calibrated by the manufacturer or by a third party certified for that purpose and following manufacturer specifications, no more than 2 months after the accuracy check conducted following the corrective actions. If the measuring device was manufactured with no possibility of calibration, it must be replaced no more than 2 months after the accuracy check conducted following the corrective actions.

When the measurement accuracy of a measuring device, except for a leak detection measuring device, indicates a reading outside of a ± 5% accuracy range, the following conditions must be followed for the entire period from the last time the measuring device showed a reading within ± 5% accuracy until the measuring device shows a return to ± 5% accuracy:

When the measurement accuracy of a leak detection measuring device indicates a reading outside of a ± 5% accuracy range, any leak survey conducted during the period from the last time the leak detection device showed a reading within ± 5% accuracy until the device shows a return to ± 5% accuracy, is considered as not meeting the requirements as per Section 9.1.7.

All measuring devices listed in Section 9.2, except for grid electricity meters, leak detection measuring devices operated by a third party certified for that purpose and portable pH meters, must be calibrated by the manufacturer or by a third party certified for that purpose and following manufacturer specifications, in accordance with the manufacturer specified frequency or every 5 years, whichever is more frequent. However, if the device is factory calibrated and the manufacturer specifies that no recalibration is required, the factory calibration then needs to be validated on-site by either the manufacturer or a certified third party in accordance with the manufacturer specified frequency or every 5 years, whichever is more frequent.

For portable pH meters, the user must perform a calibration daily or in accordance with the manufacturer specified frequency, whichever is more frequent.

9.5 Missing data

If a measuring device fails to produce data as required in Sections 9.1, 9.2 and 9.3, missing data may be substituted following the requirements in this section. If missing data cannot be substituted as per the applicable requirements, no GHG emission reductions can be quantified for the issuance of offset credits for the period during which data is missing.

In the event that periods of missing data occur more than once during a reporting period, data may be substituted to quantify:

9.5.1 Missing data from a biogas measuring device

The proponent may substitute missing data from a biogas measuring device (that is, flow meter or methane analyzer) only if the operational status of the eligible destruction devices can be demonstrated in accordance with the requirements in Section 9.6.3.1 during the period of missing data. In addition, missing data from a flow meter or methane analyzer may only be substituted in accordance with the following conditions:

For a project with biogas volume or CH4 content data missing for a period of up to 7 consecutive days, the proponent must use the appropriate substitution method set out in Table 4 to substitute the data.

For data missing for more than 7 consecutive days, only the data for the period of up to 7 days may be substituted. No data may be substituted for the period after the 7th consecutive day, and no GHG emission reductions may be quantified for the issuance of offset credits for that period.

Table 4: Missing data substitution methods for biogas measuring devices
Missing data period Substitution method
Less than 6 consecutive hours Use the average of the 4 hours immediately prior to and after the missing data period.
6 to less than 24 consecutive hours Use the 95% upper or lower confidence limit of the 72 hours prior to or after the missing data period, whichever results in greater conservativeness.
1 to 7 consecutive days Use the 90% upper or lower confidence limit of the 72 hours prior to or after the missing data period, whichever results in greater conservativeness.

9.5.2 Missing data from VS content

The proponent may substitute missing data from monthly VS content sampling in eligible manure or treated manure, as per Section 9.1.2, only if the following two conditions are met:

If the conditions for substitution listed above are met, the proponent may use the appropriate VS content value (that is, eligible manure or treated manure) from the month prior to the month of the missing VS content data to use in Equation 2 (VSSource,i,m) if missing data from eligible manure VS content, or in Equation 18 and Equation 24 (VSLTM,m) if missing data from treated manure VS content.

If the conditions for substitution listed above are not met, no GHG emission reductions from anaerobic storage (SSR 9) can be quantified for the issuance of offset credits for the period during which data is missing. The proponent must set the value of VSSource,i,m in Equation 2 and the value of VSLTM,m in Equation 18 and Equation 24 to zero. GHG emissions from all other SSRs must continue to be quantified as per Section 8.0.

The proponent may not substitute missing data from VS content sampling required for defining a project-specific MTS efficiency rate, as per Section 9.1.4.

9.5.3 Missing data from pH measurement for a project chemical MTS

For a project including a chemical MTS with pH data missing for a period of up to 7 consecutive days, the proponent must use the 90% upper or lower confidence limit of the 72 hours prior to or after the missing data period, whichever results in greater conservativeness.

After the 7th consecutive day of missing pH data, the project chemical MTS is considered not operational as per Section 9.6.1, and no missing data may be substituted for that period.

9.6 Operational status of a project MTS

9.6.1 Operational status of a project chemical MTS

The proponent must monitor and record pH according to Section 9.2.2.

A project chemical MTS is considered operational if the daily average pH is:

If a project chemical MTS is considered not operational for 1 month or more in the period of May to October, the project chemical MTS is considered operational again once the two following conditions are met:

In all other cases (that is, not operational for less than 1 month in the period of May to October, or not operational for any amount of time from November to April), the project chemical MTS is considered operational again once the two following conditions are met:

If during any period of time a project chemical MTS is considered not operational, the system is not functioning properly or is not operated in accordance with the manufacturer specifications, or its operational status cannot be confirmed, no GHG emission reductions can be quantified for the issuance of offset credits for this period.

9.6.2 Operational status of a project mechanical MTS

For a project mechanical MTS, the proponent must monitor and record an indicator of operational status appropriate for the system using a monitoring instrument in accordance with the manufacturer specifications, such as manure input, motor speed, system pressure, or temperature.

If during any period of time a project mechanical MTS or the monitoring instrument is not functioning properly or not operated in accordance with the manufacturer specifications, or the operational status cannot be confirmed, no GHG emission reductions can be quantified for the issuance of offset credits for this period.

9.6.3 Operational status of a project AD MTS

For a project AD MTS, the proponent must monitor and record an indicator of operational status appropriate for the system in accordance with the manufacturer specifications, such as biogas production, digester temperature, or pH.

If during any period of time a project AD MTS, including an eligible destruction device, or the monitoring instrument is not functioning properly or not operated in accordance with the manufacturer specifications, or the operational status cannot be confirmed, no GHG emission reductions can be quantified for the issuance of offset credits for this period.

9.6.3.1 Operational status of eligible destruction devices

For a project AD MTS, the proponent must monitor and record the operational status of all eligible destruction devices by using, for each destruction device, a monitoring instrument that records the operational status at least once per hour.

For a flare (open or enclosed), the operational status must be determined based on data from a thermocouple. For the flare to be considered operational, the thermocouple must indicate that the flare temperature meets or exceeds 260˚  C (the minimum temperature for CH4 destruction).

For all other eligible destruction devices listed in Table 1, the destruction device monitoring instrument must monitor and record an indicator of operational status appropriate for the destruction device such as energy output.

Requirements for the operational status of eligible destruction devices apply to all eligible destruction devices located within the project site, including those located at an adjacent destruction facility.

In cases where biogas is combusted in an eligible destruction device located at an adjacent destruction facility, the proponent must obtain the monitoring data demonstrating the operational status of the eligible destruction device; otherwise, no GHG emission reductions generated with this device can be quantified for the issuance of offset credits.

10.0 Records

In addition to the record keeping requirements specified in the Regulations and to the documents required in Section 11.0, the proponent must keep records of all data and information that support the implementation of the project and verification, including invoices, contracts, metered results, calculations, databases, photographs, equipment maintenance, accuracy checks and calibration records. The records must be kept and retained at the location and for the period of time specified in the Regulations.

10.1 General records

The proponent must keep records of the information about any eligible project MTS, measuring devices, monitoring instruments and meters located at the project site, including adjacent destruction facilities.

10.1.1 Project site

The proponent must keep a record of the information about the project site, including:

10.1.2 Eligible manure

The proponent must keep a record of the information about the eligible manure treated by the project MTS, including:

10.1.3 Project activities

The proponent must keep a record of the information about the project activities, including:

10.1.4 Measuring devices and monitoring instruments

The proponent must keep a record of the information about the measuring devices and monitoring instruments in the project, including:

10.1.5 Quantification

The proponent must keep a record of the information used for the quantification of the GHG emission reductions generated by the project, including:

10.2 Records specific to a project chemical MTS

The proponent must keep a record of the information about the project chemical MTS and the acidified liquid treated manure, including:

10.3 Records specific to a project mechanical MTS

The proponent must keep a record of the information about the project mechanical MTS, including:

10.4 Records specific to a project AD MTS

The proponent must keep a record of the information about the project AD MTS, including:

If applicable, the proponent must keep a record of the information about the displacement of fossil fuels by eligible biogas, as per Sections 3.2 and 4.4, including:

11.0 Reporting

In addition to the reporting requirements specified in the Regulations, the proponent must include the following in project reports.

In the initial project report, the proponent must include:

In any project report, the proponent must include:

Page details

2026-09-11
